Product Manual — Doc. 9243B Horizon® 2 Dimmers, Switches, and Keypads • 45
HZ2-DIMUEX Specifications
Product specifications for the HZ2-DIMUEX.
Product Specifications
Load Control
Load Type LED, Incandescent, Magnetic Low Voltage, Electronic Low Voltage
Load Rating 600 W/VA maximum;
No minimum load
Preset Fade Time 1 second (default), when operated without a control system;
Fade time is adjustable when controlled by a control system
Power Requirements
120VAC, 50/60 Hz;
Requires neutral wire connection
Controls
Airgap (1) Switch at the bottom of the device;
Controls power to the device and connected loads
Pushbutton (9) Pushbuttons, located under the button assembly;
Pushbuttons are actuated by the button assembly that is installed
Button Assembly (1) Button assembly included;
Compatible with Style1–6 button assemblies
Setup (1) Pushbutton;
Front of the faceplate must be removed to access the pushbutton;
Can be used to set the local LED backlight color theme or calibrate the ambient light
sensor
LED Indicator and Light Sensor
LED Feedback (5) RGB LED backlights;
Supports one local color theme for all LEDs;
Supports one alternate color theme for each backlit position
Light Sensor (1) Photosensor with adjustable sensitivity;
Detects the ambient room light level to activate day or night mode and autodimming
the backlight
NOTE: Light sensor performance may be affected by obstructions placed below the keypad.
Wireless
RF Transceiver infiNET EX® 2-way RF, 2.4 GHz ISM Channels 11-26 (2400 to 2483.5 MHz), default
channel 15;
IEEE 802.15.4 compliant
