Crestron Green Light Express™ Dimming Panel

Override Mode

The Override mode overrides the control system program and sets all of the output states to the stored override

values. For instructions on saving override settings, refer to “Save Override Settings” below.

To enable Override mode, press and release the OVR button. The OVR LED flashes slowly.

NOTE: If the Override mode was enabled from an external device (i.e. a contact closure is present on the

OVERRIDE terminals), the OVR LED will flash quickly. Pressing the OVR button has no effect.

To disable Override mode, press the OVR button again. The OVR LED extinguishes and the outputs return to the

states set by the control system program.

NOTE: If override states have not been stored, the factory default override state is all loads on.

Save Override Settings

The state of each output can be saved as an override setting, which can be automatically recalled when the Override

mode is enabled.

NOTE: The control system program has a setting that can prevent locally saving the override state. If this setting is

enabled, the display shows “Er” when trying to save override states. For more information, refer to the SIMPL

Windows help file.

To save the states of all outputs as the override setting, press and hold the OVR button for three seconds until the

OVR LED blinks once.

System Operation and Commissioning

This cabinet has been designed as a component of a programmed Crestron system. System commissioning by an

authorized Crestron representative

must be performed to ensure system operation.

Once the cabinet has been wired and the modules have been tested, contact Crestron at 1-888-CRESTRON

[1-888-273-7876] to schedule commissioning.

Installation Guide – DOC. 6889B Crestron Green Light Express™ Dimming Panel • 17
