Dimming Panel Crestron Green Light Express™
Wiring
NOTE: All wiring must be installed in accordance with all local and national electrical codes.
NOTE: Refer to the torque settings specified on pages 11 and 12.
Crestron Green Light Express dimming panels are shipped with GLXX-2DIM8 dimming modules installed. The
following must be performed after mounting the panel:
• Connect incoming feed conductors to the input terminals and connect loads to output terminals (section A
of the following diagram)
• Connect control wiring (section B of the following diagram)
SERVICE
SCREWDRIVER
A
B
CLASS 2
WIRING ONLY
FEEDS
FROM
BREAKER
PANEL
TO
LOADS
FEEDS
FROM
BREAKER
PANEL
TO
LOADS
10 • Crestron Green Light Express™ Dimming Panel Installation Guide – DOC. 6889B
