12 • DIN-GWDL and DIN-GWDL-SPLTR Product Manual — Doc. 9096C
Controls and Indicators
MODE Rotary Dial (1) Dial for selecting different test modes for DMX-C outputs
SELECT Button (1)Push button function varies based on test mode selected
RESET Button (1)Recessed push button for software reset
PWRLED (1) Red LED indicates operating power is supplied
ACTIVE LED (1)Red LEDindicates device is active
ETHERNET LED (1)Red LEDindicates ethernet activity
I/O LED (1)Red LEDflashes when a change occurs on the INPUT or OUTPUT terminals
N/ALED Not used
DMXLED (1)Red LEDindicates DMX-Cactivity
OUTPUTLED (1)Red LEDindicates that the device is actively controlling the lights
Power
PoE IEEE 802.3af Class 2 (6.49 W) compliant;
Use CEN-SW-POE-5 or other IEEE 8.2.3af compliant PSE
Power Pack (Optional) 9-48VDC;
Use Crestron power supplies PW-2407-RU, PW-2407WUL, DIN-PWS60, DIN-
PWS30-277 (all sold separately)
Power Consumption 5W max
Environmental
Temperature 32° to 122°F (0° to 50°C)
Humidity 10% to 90% RH (noncondensing)
