5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Retherm
Humidity Oven
FL-2392
Rev. 0 (5/16)
Page 3 of 15
INSTALLATION INSTRUCTIONS
UNIT SPECIFICATIONS: Units below use six (6) elements (3000 watts each). Units are rated 18,000 watts.
MODEL NOS.
ELECTRICAL SPECS
(AC SERVICE)
ELEC. LOAD
POWER SUPPLY REQUIREMENT
ALL 3 PHASE IS 3 WIRE + GROUND
VOLTS PHASES HZ AMPS VOLTS AMPS PHASES VOLTS RECEPTACLE
RR1332WDE(DX)2083 208 3 60 50 208 60 3 208 15-60R
RR1332WDE(DX)2403 240 3 60 44 240 60 3 240 15-60R
RR1332WDE(DX)4803 480 3 60 22 480 30 3 480 L16-30R
UNIT SPECIFICATIONS: Units below use six (6) elements (2000 watts each). Units are rated 12,000 watts.
RR1332WDE(DX)12K2083 208 3 60 34 208 50 3 208 15-50R
RR1332WDE(DX)12K2403 240 3 60 29 240 50 3 240 15-50R
RR1332WDE(DX)12K4803 480 3 60 15 480 30 3 480 L16-30R
UNIT SPECIFICATIONS: Units below use six (6) elements (1325 watts each). Units are rated 8,000 watts.
RR1332WDE(DX)8K2081 208 1 60 40 208 50 1 208 6-50R
RR1332WDE(DX)8K2401 240 1 60 35 240 50 1 240 6-50R
All models are designed for AC Service. Model numbers may have the letters: Z or S.
HOW TO INSTALL OVENS:
1. Remove all packing material from inside and outside
of oven.
2. Position oven on level oor. After shipping, you may
have to adjust legs to ensure proper t of rack into
cabinet.
3. Plug power cord into proper wall receptacle.
4. MANUAL FILL: Fill water pan with three (3)
gallons of HOT water (see CAUTION).
5. AUTO FILL: Attach water valve on back bottom of
unit to water supply (see “How to Use Automatic Fill
Kit” on page 7).
LOW WATER LIGHT:
MANUAL FILL: When water needs to be added to the
pan, the Low Water Light will stay on and the humidity
will not work until the pan is relled.
AUTO FILL: If water level is low and water supply is not
connected, an error code will display after a time limit.
HOW TO CHANGE FROM °F TO °C (if needed)
1. Push the switch on; the light will come on.
2. Push and hold the “SET” button and the button in the
lower left hand corner together for 5 seconds.
You have now entered into the menu.
3. Scroll over the”Unit” and change it to “C” , then scroll
to the “END”.
VENTING YOUR OVEN:
1. The purpose of ventilating hoods is to direct and
capture smoke, grease-laden vapors, heat, odors,
or fumes.
2. Low temperature equipment (maximum
temperature 250°F/121°C) does not produce heat,
odors, fumes, grease-laden vapors or smoke and
is not required to be vented.
3. Most jurisdictions consider our low-temperature
ovens (maximum temperature is 350°F/177°C) as
low-heat appliances not requiring vent hoods.
4. Installation must conform with local codes. The
authority having jurisdiction of enforcement of
the codes will have the responsibility for making
interpretations of the rules.
C AUTION
