ENGLISH

CARBIDE SERIES

100R SILENT EDITION

Frequently Asked Questions

10. Installing the Front I/O Connectors

9. Powering the Case Fans

See your motherboard’s

manual for front panel header

locations and pin-outs.

USB 3.0

HD AUDIO

POWER SW

RESET SW

POWER LED +

POWER LED -

1. How do I remove the I/O Panel ?

If needed, you can uninstall your I/O panel by removing the front

fascia (step 5) then unscrewing the 2 screws at each side of panel.

(see drawing)

2. Does the polarity matter with the I/O panel’s power and reset header?

No, only the LED headers.

3. Who should I contact if I received my case damaged or one of the

fans is no longer working?

Please go to support.corsair.com and request an RMA

so that we can replace the damaged part(s).

4. Where can I mount a fan?

To learn more about this case visit the product page at corsair.com.

Fan Mount Locations

Front x2 120mm or p7-x2 140mm

Top x

Rear 120mm

Bottom x

Side x

Mid x

100R FAQ

1. Connect the SATA power

connector to the PSU SATA

power cable.

2. Connect the 3 or 4-Pin

fan connecter to the case

fan header.

3. Push the fan speed selector

button on your case to

toggle fan speed.
