17
OPERATIONS MANUAL
REFRIGERATED BASES & PIZZA PREP TABLES
MOUNTING CASTER SUPPORT PLATES
If the standard stem casters on a cabinet are not properly main-
tained and tightened, or if the unit is excessively overloaded and
moved around, the threaded inserts in the bottom of the cabinet
can become stripped, twisted or collapsed. If this occurs and
the stem casters cannot be mounted securely, rigid caster sup-
port plates can be fitted to provide the strength needed to safely
use your cabinet. Each caster support plate assembly is made
of heavy gauge galvanized steel, with (2) casters attached for
maximum rigidity. The plate has holes that allow you to fasten
the plate assembly to the bottom of the cabinet with sheet metal
screws and bolts. Contact the factory to obtain the correct parts
for your model.
IMPORTANT NOTE: Always wear proper work gloves and
use appropriate safety equipment. You may CAREFULLY
lay the cabinet on it’s back, but only FOR A BRIEF PERIOD
OF TIME. Caution must be taken to ensure you DO NOT
DAMAGE the louvered back panel, refrigeration system
components, or copper tubing located behind the panel.
The cabinet must be properly blocked, to allow room to
get your hands in to lift without damaging the cabinet or
crushing the vents on the back panel. DO NOT PLUG-IN
OR OPERATE THE REFRIGERATION SYSTEM FOR AT
LEAST THREE (3) HOURS AFTER RETURNING THE UNIT
TO AN UPRIGHT POSITION, AS THIS CAN DAMAGE THE
COMPRESSOR.
To install caster support plate assemblies, you will need a 3/4”
open end wrench (or a large adjustable wrench), a drill with a
1/8” bit and a Phillips bit (or a Phillips-Head screwdriver) plus
work gloves. A 1/2-13 thread tap is also recommended, to repair
any damage to the threaded inserts in the cabinet. Unload all
product and carefully lay the cabinet on its back. Remove the old
stem casters by unscrewing them from the cabinet. If a caster or
threaded insert has been stripped or cross-threaded, it may be
necessary to use a wrench to loosen the caster.
Hold one of the support plate assemblies under the cabinet as
shown (see Figure 16). Position it so the slotted holes at the end
of the plate line up with the threaded inserts in the bottom of the
cabinet (where the stem casters were attached). Attach the plate
assembly to the cabinet by putting a 1/2” x 1-3/4” long bolts and
flat washer through the slot in the support plate and screwing
into each of the threaded inserts in the bottom of the cabinet.
Snug the bolts down, but do not tighten them completely. If
one of the threaded inserts is stripped or damaged, a thread tap
should be used to clean the threads.
FIGURE 15: Drawer Cage
CAGE MOUNTING
HOLES
BREAKER CORNERS
BREAKER COVERS
NOTCHES WILL BE
SURROUNDING
BREAKER CORNERS
REMOVE SIDE
DRAWER CAGE
through each of the four slots located in the rear of the cage and
into the interior rear of the unit.
IMPORTANT NOTE: These screws should NOT be tight!
The purpose of these screws is not to secure the cage
to the unit, but to limit the side-to-side movement of the
rear of the cage.
Once the drawers are installed, the cage rear should be able to
find its own place so the drawers can open and close freely.
Locate a short piece of breaker cover and snap into place over
the exposed portion of the primary breaker, angling up into the
upper breaker corner, and then sliding downward so its bottom
edge sits against the top of the cage. Repeat for the other side.
Repeat the entire procedure for each additional opening requir-
ing drawers.
Install the drawers by following the instructions in “Removal
and Adjustment of Drawers” section of this manual.
NOTE: If the drawer front appears crooked (once all the
drawers are installed and closed), they can be adjusted
by loosening the five screws that hold the drawer front to
the drawer body, adjusting as necessary, and retightening
the screws.
