TROUBLESHOOTING
Problem Possible cause Remedy
When the hob is switched
on the household wiring
protection reacts.
The current load is too high
for household wiring.
Check that the input of all switched-on units does
not exceed the maximum load of the household
wiring. Make sure that the parameters on the
rating plate are compatible with the mains
voltage and the current protection.
After pressing the ON/OFF
button of the hob, the hob
turns on, but the display for
each cooking zone does not
work .
Power electronics
malfunction.
Replacement of power electronics required.
Contact an authorized service centre.
Control panel electronics
malfunction.
Replacement of control panel electronics
required. Contact an authorized service centre.
After setting the power level
of the cooking zone, the
cooking zone does not work.
Overheating of the cooking
zone.
The temperature of the cooking zone is too high.
Check that the cooling fan located at the bottom
of the hob functions well. If the fan is working,
contact an authorised service centre.
Cooling fan malfunction.
Cooling fan replacement required. Contact an
authorized service centre.
Power electronics
malfunction.
Replacement of power electronics required.
Contact an authorized service centre.
The cooking zone is hot but
the control panel does not
work.
Control panel or power
electronics malfunction.
Press the ON/OFF button on the hob again and
re-set the cooking zones.
The hob switches o during
cooking.
The ON/OFF button has
been pressed accidentally.
Press the ON/OFF button on the hob again and
re-set the cooking zones.
Cracks or tears in the ceramic
glass hob.
Cookware has been
dropped on the hob, which
damaged the ceramic glass
hob.
Disconnect the appliance immediately from the
power supply by pressing the ON/OFF button
or the appropriate circuit breaker. Contact an
authorized service centre.
ERROR MESSAGE
Code Problem description Possible cause
E0 Error 0
Replacement of power supply electronics
required. Contact an authorized service center.
E1/E2/
E7
Malfunction of the cooking zone temperature
sensor.
Temperature sensor replacement required.
Contact an authorized service center.
C1 The cooking zone temperature is too high.
Wait for the cooking zone temperature to drop.
Press the ON/OFF button to restart the hob.
E3/E4 Temperature sensor failure. Contact an authorised service centre.
EL/EH The power supply voltage does not match. Check the voltage or contact a specialist.
EU Communication error between electronics. Contact an authorised service centre.
ENERGY EFFICIENCY
Product information according to EU Directive 66/2014 for the domestic market within the EU
Model identication SDV3860
Type of hob Build-in hob
Number of cooking zones
and/ or areas
4
Heating technology Radiant cooking zones
Diameter of circular cooking
zones (Ø)
Left front
Left rear
Right rear
Right front
23.0 cm
16.5 cm
27.5*16.5 cm
16.5 cm
Dimension of non-circular
cooking zones (exi/bridge)
/ /
„Energy consumption per cooking
zone or area calculated per kg
(EC electric cooking)“
Left front
Left rear
Right rear
Right front
185,7 Wh/kg
173,7 Wh/kg
195.8 Wh/kg
178.7 Wh/kg
Energy consumption for the hob
calculated per kg (EC electric hob)
183,5 Wh/kg
ENVIRONMENTAL CONCERNS
• Packaging materials and old appliances should be recycled.
• Packaging materials may be disposed of as sorted waste.
• Dispose of the plastic bags made of polyethylene (PE) as sorted waste.
Recycling of the appliance at the end of its lifespan:
This appliance conforms the European Union Directive 2012/19/EU on Waste Electrical and Electronic
Equipment (WEEE Directive). The symbol on the product or on its packaging indicates that this product
may not be treated as household waste. Instead it should be taken to the appropriate collection
point for the recycling of electrical and electronic equipment. By ensuring this product is disposed
of correctly, you will help prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of this product. The disposal
of such material must be performed in accordance to the regulations of waste disposal. For more
detailed information about recycling of this product, please contact your local council, your household
waste disposal service or the shop where you purchased the product.
The product meets all the necessary requirements of the EU directives applicable to the specic product.
Changes in text, design, and technical specications are subject to change without notice and we reserve the right to
change them.
