EN EN
80 81
USING THE REMOTE CONTROL
1. Automatic cleaning/pause
2. Forward movement
3. Left turn
4. Suction power adjustment
5. Quiet mode
6. Switching the button illumination off/on
7. Start/stop charging
8. Turn right
9. Find a robot
10. Adjusting water flow rates
11. Local cleaning
Note: To ensure that all the correct settings are effective,
you must point the remote control at the front of the
robotic vacuum cleaner from close proximity.
DAILY MAINTENANCE
Main brush (clean regularly)
1. Turn the appliance over and press the latch on the
main brush cover to pull it out.
2. Remove dust from inside and from inside the main
brush with a small brush and clean the main brush.
3. Reassemble the main brush and press firmly on the
cover until the latch clicks into place.
Side brushes (clean regularly)
1. Turn the robot over and pull the side brushes upwards.
2. Remove the hair and dirt and put the side brushes back
on by pushing them in. Make sure the left side brush (L)
and the right side brush (R) match the L and R symbols
on the bottom cover of the vacuum cleaner.
Note: It is recommended to change the side brushes
every 3-6 months to ensure their cleaning effect.
Dust container and filter grid (clean regularly)
1. Press the button and pull the dust container
backwards.
2. Open and clean the dust container.
Cleaning the filter grid (clean regularly)
1. After prolonged use, remove the HEPA filter and the
foam filter.
2. Rinse the filters with clean water.
3. Wipe the individual parts and let them air dry.
4. After drying, assemble them in the correct order:
grid - foam filter - HEPA filter.
Note:
• Rinse the filter grid with clean water and do not add
any detergent.
• Do not clean the filter grid with a brush or your fingers.
• Allow the filter grid to air dry for at least 24 hours.
Wiping module (clean after each use)
1. Remove and clean the cloth.
2. Wipe the water tank dry.
1
2
3
4
5
6
7
8
9
10
11
Sensors (clean regularly)
Clean the sensors with a soft cloth as follows:
1. Keep the robot switched off during cleaning. Clean the side sensor, the fall sensors, the point laser in the front and the
charging contacts at the bottom of the robot (see drawing for product description).
2. Unplug the docking station from the power supply and wipe the charging contacts on the docking station as well as
the docking station signal transmission point.
Battery
• The robot is equipped with a high-performance lithium-ion battery. To maintain battery performance, keep the
appliance charged every day.
• If the appliance is not used for a long time, turn it off and store it properly. Charge it at least every 3 months to
prevent damage to the batteries due to excessive discharge.
Firmware update
Use the mobile app to update the firmware. If new firmware is detected, update as prompted. When updating the
firmware, the battery level should be ≥50 % and the appliance must be placed in the docking station.
Docking station
• Regularly check the bag in the docking station. If the bag is full, replace it with a new one.
• Clean the charging contacts and the suction opening.
• Remove the coarse filter of the docking station and rinse it with water. Allow it to dry properly and reinstall it.
COMMON PROBLEMS
Problem Remedy
The robot cannot be
started
• If the battery is low, place the robot in the docking station and align it with the
board contacts, the appliance will start automatically (if the robot is completely off,
it can start automatically after a while).
• Do not use the appliance if the ambient temperature is below 0 °C or above 40 °C.
The robot cannot be
charged
• Move the robot off the station, make sure the docking station indicator light is
on, and make sure both ends of the docking station power adapter are properly
connected.
• In case of poor contact, clean the docking station contact points and charging
contacts on the robot or turn the side brush to the side, so as not to obscure the
contact.
The robot cannot be
recharged
The robot is too far from the docking station, place it near the docking station and try
again.
Abnormal behaviour Turn off the robot and restart it.
Unusual noise is heard
during use
The main brush, side brush or wheel may be wrapped with foreign objects, turn off the
robot and remove foreign objects.
Cleaning ability is
reduced or dust is
dropping from the
appliance
• The dust container is full. Clean it.
• The filter is clogged. Clean or replace it.
• The main brush is wrapped with foreign objects, clean it.
Wi-Fi cannot be
connected
• The Wi-Fi signal is bad. Check that the correct Wi-Fi coverage is available.
• Wi-Fi is connected in an unusual way. Reset Wi-Fi, download the latest app, and try
connecting again.
• The password is entered incorrectly.
• There is a router for the 5GHz frequency band, the robotic vacuum cleaner is
equipped only for the 2.4GHz frequency band.
