4. When wiping is complete, hold the wiper module and remove the vacuum cleaner by pulling upwards. For cleaning
instructions, please refer to under Maintenance and Cleaning.
OPERATION OF THE HANDHELD VACUUM CLEANER
1. Press the release button of the handheld vacuum cleaner, grasp the handle of the handheld vacuum cleaner
and remove it from the bar section.
2. Press the on/off button on the handheld vacuum cleaner.
3. The handheld vacuum will automatically start on high. To switch gears, you must first start the vacuum cleaner in the
pole section and switch gears before removing the handheld vacuum cleaner.
4. Press the on/off button again to switch off the vacuum cleaner.
5. Before vacuuming again, empty the dust container and clean the filters.
6. Return the handheld vacuum cleaner to the bar section.
Accessories
Choose accessories according to the nature of the
surface to be cleaned.
Crevice nozzle - suitable for wall corners, car
upholstery, radiators, etc.
Crevice nozzle with brush - suitable for bed
linen, fabric, sofas, shelves, etc.
Note: Accessories must be removed before
charging. The crevice nozzle and brush nozzle can
be stored in the charging stand.
CLEANING AND MAINTENANCE
Emptying the dust cup
Empty the dust cup after each use or when the dust level exceeds the maximum level. Always switch off the appliance
before cleaning it. The surface of the vacuum cleaner and the charging base can be wiped with a soft damp cloth.
• Remove the attachments from the handheld vacuum cleaner, if fitted.
• Press both buttons simultaneously to release the dust container and remove the container from the hand-held
vacuum cleaner.
• Pull upwards to remove the filters from the dust container and empty the dirt. Rinse the dust container with water
and allow it to dry completely. Wipe the surface of the container with a damp cloth.
Cleaning filters
• Remove the HEPA filter from the coarse filter and knock out the filters. If the filters are heavily soiled, they can be
washed with water and then allowed to dry completely.
• Place the HEPA filter in the coarse filter and then place the filters back in the dust container.
• Put the dust container back into the handheld vacuum cleaner.
• Insert the handheld vacuum cleaner into the rod section.
Notice:
• Do not use any cleaning agents to clean the HEPA filter.
• We recommend dry cleaning only to preserve the HEPA filter's filtration capabilities. Washing the HEPA filter
with water reduces its filtering capacity! It is recommended to change the HEPA filter according to the frequency
of vacuuming, approximately every 3 months.
Wiping module
• Try to keep the wiper module dry when not in use. Rinse the attachment under running water and leave it to drip
upside down, e.g. in the sink.
• The cleaning fabric can be washed in a washing machine at a temperature of up to 60 °C.
• Allow the cleaning cloth to dry completely.
Cleaning the rotary brush
• Pull the button on the side of the floor head to release the
brush.
• Pull the cap upwards and remove with the rotary brush.
• Remove the hair from the rotary brush, or also loosen the
brush cap and remove the coiled hair.
• Reverse the procedure to reassemble the turbo brush.
TROUBLESHOOTING
Problem Cause Remedy
Rotary brush does not rotate. Rotary brush is blocked.
Clean the rotary brush as described
in the instruction manual.
The vacuum cleaner is not
vacuuming.
The dust cup is full. Empty the dust cup.
The filter is dirty.
Clean the filter as described in the
instruction manual.
The vacuum cleaner is not
working.
The vacuum cleaner is discharged.
Charge the vacuum cleaner as
described in the instruction manual.
