4. Specifications
Technical
USB Protocol SuperSpeed USB 3.2 Gen 1
Transmission Rate Up to 5Gbps
Transmission Distance
5Gbps = Cat 5e/6 70m (230ft)
5Gbps = Cat 6A/7 100m (330ft)
5Gbps = USB cable 1.5m (4.9ft) Also supports active USB cables
Cat Cable Requirements
Cat6A cable is recommended for optimal performance.
ESD Protection
IEC 61000-4-2: ±8kV (Air-gap discharge), ±4kV (Contact discharge)
Connections
Transmitter
Input:
1× HOST 1 [USB Type C, 24-pin female]
1× HOST 2 [USB Type B, 9-pin female]
Output: 1× USB-C DEVICE [USB Type C, 24-pin female]
2× USB-A DEVICE [USB Type A, 9-pin female]
1× HDBT-USB3 [RJ45 connector, 24V PoC]
Control: 1× RS-232 [3pin-3.5mm phoenix connector]
1× FSYNC [1pin-3.5mm phoenix connector]
1× SERVICE [USB Type C, firmware update port]
Receiver
Input:
1× HDBT-USB3 [RJ45 connector, 24V PoC]
Output: 3× USB-A DEVICE [USB Type A, 9-pin female]
1× USB-C DEVICE [USB Type C, 24-pin female]
Control: 1× RS-232 [3pin-3.5mm phoenix connector]
1× FSYNC [1pin-3.5mm phoenix connector]
1× SERVICE [USB Type C, firmware update port]
Mechanical
Housing Metal Enclosure
Color
Black
Dimensions
Transmitter / Receiver: 140mm [W] × 75mm [D] × 23mm [H]
Weight
Transmitter: 313g; Receiver: 318g
Power Supply
Input: AC 100~240V 50/60Hz
Output: DC 24V/3.75A
Power Consumption
Transmitter: 23W (Max); Receiver: 35W (Max)
Operating Temperature
0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F
Operating Humidity
20%~80% relative humidity, non-condensing
Storage Humidity 10%~90% relative humidity, non-condensing
