observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as re-orienting

or relocating the device.

b Over the frequency range 150 kHz to 80 MHz, eld strengths should be less than 3 V/m.

THE DEVICE IS INTENDED FOR USE IN THE ELECTROMAGNETIC ENVIRONMENT SPECIFIED BELOW. THE CUSTOMER

OR THE USER OF THE DEVICE, SHOULD ASSURE THAT IT IS USED IN SUCH AN ENVIRONMENT.

Test Frequency

(MHz)

Band

a

Service

a

Modulation

a

Maximum

Power (W)

Distance (M)

Immunity Test

Level (V/m)

385 380-390 TETRA 400. Pulse Modulation

b

18Hz 1.8 0.3 27

450 430-470 GMRS 460. FRS 460. FM

c

+5kHz sine 2 0.3 28

710

704-787 LTE Band 13. 17.

Pulse Modulation

b

217 Hz

0.2 0.3 9745

780

810

800-960

GSM 800/900.

TETRA 800. iDEN 820.

CDMA 850. LTE.

Nand 5.

Pulse Modulation

b

18 Hz

2 0.3 28

870

930

1720

1700-1990

GSM 1800. CDMA.

1900.

GSM 1900. DECT.

LTE Nand 1, 3.

4, 25; UTMS.

Pulse Modulation

b

217 Hz

2 0.3 28

1845

1970

2450 2400-2570

Bluetooth WLAN.

802.11 b/g/n.

RFID 2450.

LTE Band 7.

Pulse Modulation

b

217 Hz

2 0.3 28

5240

5100-5800 WLAN 802. 11 a/n.

Pulse Modulation

b

217 Hz

0.2 0.3 95500

5785

NOTE If necessary to achieve the IMMUNITY TEST LEVEL, the distance between the transmitting antenna and the ME EQUIPMENT or ME SYSTEM may

be reduced to 1m. The 1m test distance is permitted by IEC 61000-4-3.

a) For some services, only the uplink frequencies are included

b) the carrier shall be modulated using a 50% duty cycle square wave signal.

c) As an alternative to FM modulation at 18 Hz may be used because while it does not represent actual modulation, it would be worst case.
