7
Figure
3
-
6
Fan Guard and Air Diverter Shown in Installed Position
The fan guard helps protect the operator from injury caused by the rotating fan blades.
Never operate a SteamChef without the fan guard properly installed.
Operating a SteamChef without the fan guard properly installed can cause injury, equipment
damage, and reduced performance.
F. Install the Fan Guard and Air Diverter
• See Figure 3-6
1. Hold the fan guard so that the large ends of the keyholes are towards the bottom of the steamer.
2. Place all four openings over the mounts located on the rear wall of the steamer
3. Pull it down so that the narrow ends of the slots are pulled tight over the mounts. See Figure 3-6.
4. Place the air diverter onto the fan guard as shown.
FAN GUARD
KLEANSHIELD
Figure
3
-
7
Inspecting Compartment
Interior Accessories
(Model 22CET3.1 shown)
REMOVABLE
PAN RACKS
FAN GUARD SHOWN
PULLED DOWN TO
LOCK IT IN PLACE
AIR DIVERTER
FAN GUARD
LARGE END OF KEYHOLES
AT BOTTOM
AIR DIVERTER
