6
Never operate a SteamChef without the KleanShield properly installed.
The properly installed KleanShield™ helps protect the operator from scalding water
splashing out of the reservoir, and helps prevent drain blockage.
Operating a SteamChef without the KleanShield™ properly installed can cause injury,
equipment damage,
and reduce performance.
D. Install/Remove the Slide Racks (Pan Racks)
• See Figure 3-3. Each rack has four loops; two
top, and two bottom.
1. Hold the slide rack so the ends of the hanger
loops are towards compartment wall.
2. Slide one rack into the cooking compartment
with the loop side closest to the compartment
wall and rack slots horizontal.
3. Hook the loops over the top and bottom pins
4. Repeat steps 1, 2, and 3 for the other rack.
E. Install/Remove the KleanShield
• Note: The KleanShield™ is dishwasher safe.
• To Install the KleanShield:
1. Remove the pan racks.
2. Place the KleanShield into the SteamChef so the drain trough pipe slips into the
KleanShield™ drainpipe at the rear of the cooking compartment.
3. Carefully lower the front of the KleanShield™ so the Water Level Sensor Guard is behind
the probes and the front legs rest on the bottom of the cooking compartment.
• To Remove the KleanShield, turn off the SteamChef and wait for it to cool, remove the pan
racks, carefully lift the front of the KleanShield, lift the drain trough pipe from the drain pipe, and
remove the KleanShield™ from the cooking compartment.
Figure
3
-
4
KleanShield
Figure
3
-
5
KleanShield
Installation
(SteamChef 3.1 shown)
FIT UP OF
KLEANSHIELD
PIPE
Figure
3
-
3
Slide Rack Installation
