33
P1713E-EN
2013-12
EN
6.6 Wiring Plan ..VK.., ..WK..
..VK..T/ ..M
..WK..T/..M
6.7 Connection of Measuring Devices
Only measuring devices which are galvanically separated from the protective earth conductor are permissi-
ble for measuring the torque / angle encoder signals directly on the transducer (e.g. oscilloscope with isola-
tion transformer, etc.).
E
F
G
M
H
J
K
A
B
L
C
D
ws
sw
rt
gn
X
+5V
WIA
WIB
0V
sw
rt
gn
ws
Sensor for angle measurement
Cable connection for angle encoder
Rotor electronics
Stator antenna
Attachment side
a00329_1.eps
Standard - clockwise rotation
Solder the cables on soldering pads of the same colour
(Bridge wiring / rotor sleeve)
ATTENTION
!
