Je bekijkt pagina 25 van 54
25
P1713E-EN
2013-12
EN
Electrical data
Thermal data
4.5 Pin-Out
Pin-out motor and transducer plug
Motor code 1B.. 2B.. 3B.. 4B..
Number of phases 33 3 3
Connection impedance
1)
1) Measured between two phases
[ Ohm ] 24 7.7 2 1.1
Inductance
1)
[ mH ] 20 14.7 6 3.1
Voltage constants
2)3)
2) Sine peak value
3) -10 %
[ mV/min
-1
] - 56 56 37
Torque constants
2)
[Nm/A] 0.35 0.463 0.463 0.306
Current at
2)
[A] 9 20.5 34 65
Max. peak current
2)
4)
4) The values specified apply to operation within the temperature range of 0 - 40° C. They may not be exceeded,
even for a short period of time, since this would lead to the risk of a magnetic weakening.
[A] 12 25 50 75
Electrical time contants [ ms ] 0.83 1.9 3 2.8
Motor code 1B.. 2B.. 3B.. 4B..
Max. ambient temperature [ ° C ] 40 40 40 40
Insulation class according to VDE 0530 FF F F
Thermal time constants min 16 20 35 35
Temperature rise without cooling K/W 1.25 1.15 0.73 0.70
Pin on
29 pin plug
Signal designation Conductor colours (in the motor) Pin on 12 pin plug
to the transducer
1)
Motor type
BB/BC
Motor type
BUB/BUC
GND PE Green/yellow -
1 Phase A (U) Red Green -
2 Phase B (V) Green Red -
3 Phase C (W) Black -
H Resolver S1 Yellow Blue -
G Resolver S3 Blue Yellow -
K Resolver S2 Red -
J Resolver S4 Black -
S Resolver R1 Red/white -
T Resolver R2 Yellow/white -
N Thermal sensor signal Green + black -
M Thermal switch signal White -
Y Supply -12V Violet
1)
A
B Angle track A White
1)
B
E Torque signal Green
1)
C
R Torque signal 0 V Yellow
1)
D
X Supply 0 V Pink
1)
E
Q Supply +12 V Brown
1)
F
P Angle track B Blue
1)
G
C RxD+ (Tool) Red
1)
H
