24
P1713E-EN
2013-12
EN
4.4 Technical Data
Motor data
Mechanical data
Motor code 1B.. 2B.. 3B.. 4B..
Intermediate circuit voltage [ V ] 320 320 320 320
Max. speed [ min
-1
] 7000 5000 5000 7000
Rated speed [ min
-1
] 3000 3000 3000 3000
Rated current
1)
1) Sine peak value
[A] 1.6 2.8 4.8 7.3
Rated output
2)
2) These values apply to motor assembly on contact surfaces made of aluminium of min. 0.15m
2
with a mini-
mum thickness of 10 mm or a equivalent metal surface
[ W ] 140 370 630 630
Operating mode according to
VDE 0530
S 1 S 1 S 1 S1
Sense of rotation Reversible Reversible Reversible Reversible
Design B14 B14 B14 B14
Flange DIN 42948 - - C80 C80
Type of connection Plug connection
Motor code 1B.. 2B.. 3B.. 4B..
Mass moment of intertia [ kgm
2
] 0.012 - 10
-3
0.056 - 10
-3
0.27 - 10
-3
0.27 - 10
-3
Rated torque
1)
1) These values apply to motor assembly on contact surfaces made of aluminium of min. 0.15m
2
with a mini-
mum thickness of 10 mm or a equivalent metal surface
[Nm] 0.45 1.35 2 2
Max. continuous torque
at a standstill
1)
[Nm] 0.51 1.45 3.5 3.5
Peak torque [Nm] 2.5 7.5 12.5 16
Speed change per torque [ min
-1
x Ncm
-1
]
1)
16.3 3 0.77 0.97
Mechanical time constants [ ms ] 2.5 2 2.52 3.2
Friction torque [Nm] 0.08 0.1 0.2 0.2
Rotor weight [ kg ] 0.35 0.76 1.65 1.65
Motor weight [ kg ] 1.2 3.1 6.5 6.5
Motor weight with rotary
encoder
[ kg ] 1.6 3.5 6.9 6.9
Ball bearing 608/6000 6200 6201 6201
F
R
(permissible radial bearing load)
2)
2) Center of the shaft journal: F
A máx.
-0.3 x F
R
[ N ] 50 120 200 200
