Color Force II Plus User Manual V1.1 13 July 2024

www.chroma-q.com

4.7. Set up Menu

Color Force

II Plus

technical operation can be changed and viewed using the Setup menu options.

Command

Description

ETC Comp

Fixture can be set for compatibility with the ETC Color Picker when using ETC consoles and HSI

mode.

DMX Data

Displays the incoming DMX levels for the assigned channels.

Fan Speed

4 Fan Speed options are accessed through the Fan Speed screen:

•

Quiet – internal fan is off. (Intensity reduced to 80%)

•

Studio – internal fan is at low speed.

•

Live – internal fan is on.

•

Live-Quiet – internal fan is automatically switched on when light output is

on and

automatically switched off when light output is off.

Rotate Disp

This button rotates the orientation of the Touch Screen Display 180 degrees

Frequency

Frequency options are viewed and selected using the PWM Frequency screen:

750 Hz, 1500 Hz, 3000Hz, 6000 Hz, 12000Hz, 24000Hz.

DMX Lost

The fixture can be set with 3 options when DMX data is lost:

•

Last data – holds the last valid DMX state

•

No Output – the fixture switches to off

•

Look – select a prerecorded Look to execute

Lock

The Touch Screen Display can be set to lock or unlock in the Lock Future screen.

Reset

Reset Settings options are accessed through the Reset Setting screen:

•

Default – Factory default settings

•

User – User defined settings

Upload ENG

The fixture can be set for light engine software uploads through this screen.

FW Version

Displays current software version.

DMX Source

Displays current DMX source – cable or wireless

Eng Temp

Tells LIVE value for temperature of all the engines in fixture.

Escape

Exit the screen without saving
