(proper).
Climate range
Permissible ambient temperature
SN
from +10°C to +32°C
N
from +16°C to +32°C
ST
from +16°C to +38°C
T
from +16°C to +43°C
Note：Given the limit values of the ambient temperature range for the climate classes for which the refrigerating appliance
is designed and the fact that the internal temperatures could be affected by such factors as location of the refrigerating
appliance, ambient temperature and the frequency of door opening, the setting of any temperature control device might
have to be varied to allow for these factors, if appropriate.
Note: When operating in an environment other than the specified climate type (i.e., beyond the rated ambient
temperature range), the appliance may not be able to maintain the desirable compartment temperatures.
Locks
If your Refrigerator is fitted with a lock, keep the key out of reach and not in the vicinity of the appliance to prevent children
being entrapped. When disposing of an old Refrigerator, break off any old locks or latches as a safeguard.
Freon-free
The freon-free refrigerant (R600a) and the foaming insulation material (cyclopentane) that is environmentally friendly are
used for the refrigerator, causing no damage to the ozone layer and having a very small impact on the global warming.
R600a is flammable, and sealed in a refrigeration system, without leakage during normal use. But, in case of refrigerant
leakage due to the refrigerant circuit being damaged, be sure to keep the appliance away from open flames and open the
windows for ventilation as quickly as possible.
INTRODUCTION
No
Description
1
Chill door
2
Thermostat
3
Drip tray
4
Shelf
5 Adjustable front feet
6 Plastic retaining
INSTALLATION
Location
When selecting a position for your Fridge/Freezer you should make sure the floor is flat and firm, and the room is well
ventilated. Avoid locating your Fridge/Freezer near a heat source, eg, cooker, boiler or radiator. Also avoid direct sunlight
in out-buildings or sun lounges. If you are placing your Fridge/Freezer in an out-building such as a garage or annex
ensure that the Fridge/Freezer is placed above the damp course, otherwise condensation will occur on the Fridge/Freezer
cabinet. When working, the refrigerator gives off heat to surroundings. Therefore, at least 30mm of free space should be
spared at the top side, more than 100mm on both sides, and above 50mm at the back
side of the refrigerator.
Heat dissipation space
When working, the refrigerator gives off heat to surroundings. Therefore, at least 30mm of
free space should be spared at the top side, more than 100mm on both sides, and above
50mm at the back side of the refrigerator.。
Dimensions in mm
W
D
H
A
B
C(
°
)
E
F
470 447 496 800 874 130±5
50
100
