4
DIMENSIONS
CMS492
CMS492C
B B
1 REMOVABLE SHELF INCLUDED
2 SPACES TOTAL AVAILABLE
0.25
6.4
TILE INSERTION SPACE
19.25
489.0
TILE WIDTH
A
8.67
220.1
ELECTRICAL INSTALL PLATE SPACE FOR
A SINGLE GANG OUTLET1.
DUAL GANG OUTLET2.
PASS THROUGH FOR DUAL GANG3.
OUTLET ATTACHED TO 1/2" CONDUIT
24.97
634.3
23.69
601.7
MOUNTING
LENGTH
0.88
22.2
TRADE CONDUIT SIZE 1/2"
METRIC CONDUIT SIZE 16mm
1.38
34.9
TRADE CONDUIT SIZE 1"
METRIC CONDUIT SIZE 27mm
1.73
44.0
TRADE CONDUIT SIZE 1-1/4"
METRIC CONDUIT SIZE 35mm
DETAIL A
SCALE 1 : 2
7.60
192.9
AVAILABLE
STORAGE HEIGHT
1.91
48.4
TOP SHELF SPACE
2.25
57.2
BOTTOM
SHELF SPACE
23.67
601.1
MOUNTING WIDTH
SECTION B-B
2.69
68.3
PIPE DROP
MIN CENTER
9.40
238.9
PIPE DROP
TRAVEL
5.02
127.5
13.63
346.1
PIPE DROP TRAVEL
B B
1 REMOVABLE SHELF
INCLUDED 2 SPACES
TOTAL AVAILABLE
ELECTRICAL INSTALL PLATE SPACE FOR
A SINGLE GANG OUTLET1.
DUAL GANG OUTLET2.
1.38
34.9
DOOR DROP
1.13
28.6
TILE INSERTION SPACE
19.25
489.0
TILE WIDTH
23.67
601.1
A
23.69
601.7
MOUNTING
LENGTH
ELECTRICAL INSTALL PLATE SPACE FOR
A SINGLE GANG OUTLET1.
DUAL GANG OUTLET2.
PASS THROUGH FOR DUAL GANG3.
OUTLET ATTACHED TO 1/2" CONDUIT
24.97
634.3
8.67
220.1
0.88
22.2
TRADE CONDUIT SIZE 1/2"
METRIC CONDUIT SIZE 16mm
1.73
44.0
TRADE CONDUIT SIZE 1-1/4"
METRIC CONDUIT SIZE 35mm
1.38
34.9
TRADE CONDUIT SIZE 1"
METRIC CONDUIT SIZE 27mm
DETAIL A
SCALE 1 : 2
7.60
192.9
AVAILABLE
STORAGE HEIGHT
1.91
48.4
TOP SHELF SPACE
2.25
57.2
BOTTOM
SHELF SPACE
23.67
601.1
MOUNTING WIDTH
SECTION B-B
Installation Instructions
CMS491/492
