3
DIMENSIONS
CMS491
CMS491C
Installation Instructions
CMS491/492
B B
1 REMOVABLE SHELF INCLUDED
2 SPACES TOTAL AVAILABLE
1.38
34.9
DOOR DROP
1.13
28.6
TILE INSERTION SPACE
19.25
489.0
TILE WIDTH
A
0-
0.25
6.4
SIDE TRIM EXTENSION
(MIN-MAX) DEPTH ADJUST
ELECTRICAL INSTALL PLATE SPACE FOR
A SINGLE GANG OUTLET1.
DUAL GANG OUTLET2.
PASS THROUGH FOR DUAL GANG3.
OUTLET ATTACHED TO 1/2" CONDUIT
12.97
329.5
8.67
220.1
0.88
22.2
TRADE CONDUIT SIZE 1/2"
METRIC CONDUIT SIZE 16mm
1.38
34.9
TRADE CONDUIT SIZE 1"
METRIC CONDUIT SIZE 27mm
1.73
44.0
TRADE CONDUIT SIZE 1-1/4"
METRIC CONDUIT SIZE 35mm
DETAIL A
SCALE 1 : 2
23.67
601.1
MOUNTING WIDTH
1.91
48.4
TOP SHELF SPACE
2.25
57.2
BOTTOM SHELF SPACE
7.58
192.4
AVAILABLE
STORAGE HEIGHT
SECTION B-B
2.59
65.9
PIPE DROP
CENTER
13.63
346.1
PIPE DROP TRAVEL
5.02
127.5
PIPE DROP
MIN CENTER
B B
1 REMOVABLE SHELF INCLUDED
2 SPACES TOTAL AVAILABLE
ELECTRICAL INSTALL PLATE SPACE FOR
A SINGLE GANG OUTLET1.
DUAL GANG OUTLET2.
1.38
34.9
DOOR DROP
19.25
489.0
TILE WIDTH
1.13
28.6
TILE INSERTION SPACE
A
0.25
6.4
SIDE TRIM EXTENSION
ELECTRICAL INSTALL PLATE SPACE FOR
A SINGLE GANG OUTLET1.
DUAL GANG OUTLET2.
PASS THROUGH FOR DUAL GANG3.
OUTLET ATTACHED TO 1/2" CONDUIT
8.67
220.1
12.97
329.5
0.88 22.2
TRADE CONDUIT SIZE 1/2"
METRIC CONDUIT SIZE 16mm
1.73
44.0
TRADE CONDUIT SIZE 1-1/4"
METRIC CONDUIT SIZE 35mm
1.38 34.9
TRADE CONDUIT SIZE 1"
METRIC CONDUIT SIZE 27mm
DETAIL A
SCALE 1 : 2
23.67
601.1
MOUNTING WIDTH
1.91
48.4
TOP SHELF SPACE
2.25
57.2
BOTTOM SHELF SPACE
7.61
193.3
AVAILABLE
STORAGE HEIGHT
SECTION B-B
