Maverick Storm 3 Profile User Manual Rev. 2

Operation

LED_HOT Overheated LED

Do a factory reset

Update software

Check connections

Check fan functions

MAGENTA

Sensor board is damaged Replace the magenta sensor board

The magnetic rod of the magenta

sensor board is dropped or installed

upside down

Check the magnetic rod

MFan1

M Fan 1 is damaged Replace M fan 1

Fan wires have poor connection Check fan wire connection

MFan2

M Fan 2 is damaged Replace M fan 2

Fan wires have poor connection Check fan wire connection

Prism

Prism sensor board is damaged Replace the prism sensor board

The magnetic rod of the prism sensor

board is dropped or installed upside

down

Check the magnetic rod

R-OPEN Thermistor open

Do a factory reset

Update software

Check connection

Replace thermistor

R-SHORT Thermistor short

Do a factory reset

Update software

Check connection

Replace thermistor

X_cm

Pan magnetic locating board is

damaged

Replace the pan magnetic locating board

Pan/tilt driver board is damaged Replace the pan/tilt driver board

X_op

Pan optocoupler board is damaged Replace the pan optocoupler board

Pan/tilt driver board is damaged Replace the pan/tilt driver board

Y_cm

Tilt magnetic locating board is

damaged

Replace the tilt magnetic locating board

Pan/tilt driver board is damaged Replace the pan/tilt driver board

Y_op

Tilt optocoupler board is damaged Replace the tilt optocoupler board

Pan/tilt driver board is damaged Replace the pan/tilt driver board

YELLOW

Sensor board is damaged Replace the yellow sensor board

The magnetic rod of the yellow sensor

board is dropped or installed upside

down

Check the magnetic rod

Zoom

Sensor board is damaged Replace the zoom sensor board

The magnetic rod of the zoom sensor

board is dropped or installed upside

down

Check the magnetic rod

ZFan1

Z Fan 1 is damaged Replace Z fan 1

Fan wires have poor connection Check fan wire connection

ZFan2

Z Fan 2is damaged Replace Z fan 2

Fan wires have poor connection Check fan wire connection

ZFan3

Z Fan is damaged Replace Z fan 3

Fan wires have poor connection Check fan wire connection

Error Code Possible Reason Potential Solution
