Maverick Storm 3 Profile User Manual Rev. 2

Error Codes

See the table below for error codes and recommended solutions:

Error Code Possible Reason Potential Solution

AFAN1

A Fan 1 is damaged Replace A fan 1

Fan wires have poor connection Check fan wire connection

BladeR Framing shutter error

Check connection of module

Make sure nothing is blocking movement

Factory reset

Software update

COLOR Color wheel

Check connection of module

Make sure nothing is blocking movement

Factory reset

Software update

CPU-B

The pan/tilt driver PCB is damaged Replace the pan/tilt driver board

CPU-B software upload failed Re-upload the CPU-B software

CPU-C

The gobo/color motor driver PCB is

damaged

Replace the gobo/color motor driver PCB

CPU-C software upload failed Re-upload the CPU-C software

CPU-D

The zoom/focus motor driver PCB is

damaged

Replace the zoom/focus motor driver PCB

CPU-D software upload failed Re-upload the CPU-D software

CPU-E

The CMY motor driver PCB is

damaged

Replace the CMY motor driver PCB

CPU-E software upload failed Re-upload the CPU-E software

CYAN

Sensor board is damaged Replace the cyan sensor board

The magnetic rod of the cyan sensor

board is dropped or installed upside

down

Check the magnetic rod

DFAN1

DFan 1 is damaged Replace Dfan 1

DFan wires have poor connection Check fan wire connection

DFAN2

DFan 2 is damaged Replace Dfan 2

DFan wires have poor connection Check fan wire connection

Focus

Sensor board is damaged Replace the focus sensor board

The magnetic rod of the focus sensor

board is dropped or installed upside

down

Check the magnetic rod

Gobo

Sensor board is damaged Replace the gobo sensor board

The magnetic rod of the gobo sensor

board is dropped or installed upside

down

Check the magnetic rod

Gobo.R

Sensor board is damaged Replace the gobo rotation sensor board

The magnetic rod of the gobo rotation

sensor board is dropped or installed

upside down

Check the magnetic rod

Gobo2

Sensor board is damaged Replace the gobo2 sensor board

The magnetic rod of the gobo2 sensor

board is dropped or installed upside

down

Check the magnetic rod

LIGHT BLOCK Sunshield error

Check to ensure that the sunshield has

moved out of the light path

Check motor
