Maverick Storm 3 Profile User Manual Rev. 2

Operation

Dimmer Curve

To set the dimmer curve:

1. Go to the Settings main level.

2. Select the Dimmer Curve option.

3. Select the dimmer curve, from Linear, Square, I Squa, SCurve or Linear2.

Pulse Width Modulation

To adjust the frequency of the pulse width modulation:

1. Go to the Settings main level.

2. Select the PWM Option option.

3. Select the frequency, from 600Hz, 1200Hz, 4000Hz, 6000Hz, or 15000Hz.

LED Power

To set the power of each LED color:

1. Go to the Settings main level.

2. Select the LED POWER option.

3. Set the LED power from 64–255.

Minimum Zoom Focus

To enable or disable the Min Zoom Focus function:

1. Go to the Settings main level.

2. Select the Min Zoom Focus option.

3. Select NO (manual independent zoom control) or YES (focus adjusts depending on zoom setting).

Preset Selection

To select a preset configuration of menu options:

1. Go to the Settings main level.

2. Select the Preset Select option.

3. Select from PRESET A (default), PRESET B, or PRESET C.

Preset Synchronization

To transfer saved Presets from one Maverick Storm 3 Profile to another:

1. Connect the Maverick Storm 3 Profile products to receive the Presets by a DMX daisy chain.

2. Make the Maverick Storm 3 Profile with the Presets to transfer the first in the DMX daisy chain.

3. Power on all of the products.

4. Set all of the products to a Control Options

other than CR MX. (DMX, ArtNet, or sACN)

5. On the Maverick Storm 3 Profile with the Presets, go to the Settings main level.

6. Select the Preset Sync option.

7. Select NO (to cancel) or YES (to transfer the Presets to the connected products).

Reset Function

To reset specific functions or the entire product:

1. Go to the Settings main level.

2. Select the Reset Function option.

3. Select the functions to reset, from Pan/Tilt, Iris/Prism, Color/CMY/Blade, Gobo/Gobo Rotate,

Frost/Animation, or All.

4. Select NO (to cancel) or YES (to reset the selected functions).

Factory Reset

To reset the product to factory settings:

1. Go to the Settings main level.

2. Select the Factory Reset option.

3. Select NO (to cancel) or YES (to reset the product configuration).

• Changes to settings automatically save to the currently selected Preset.

• If no Preset has been selected, changes to settings save to PRESET A.

• After selecting a Preset, the product will restart.

• All menu configurations are transferred except for the IP address.

• ONLY connect Maverick Storm 3 Profile products for this function!
