Maverick Storm 3 Profile User Manual Rev. 2

3. Setup

AC Power

The Maverick Storm 3 Profile has an auto-ranging power supply and it can work with an input voltage

range of 100 to 240 VAC, 50/60 Hz.

To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current

value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart.

The listed current rating indicates the product’s average current draw under normal conditions.

AC Plug

The Maverick Storm 3 Profile comes with a power input cable terminated with a Seetronic Powerkon A

connector on one end and an Edison plug on the other end (U.S. market). If the power cable which came

with the product has no plug, or if it is necessary to change the plug, use the table below to wire a plug.

Fuse Replacement

1. Disconnect this product from the power outlet.

2. Using a flat-head screwdriver, unscrew the fuse holder cap from the housing.

3. Remove the blown fuse and replace with another fuse of the same type and rating (F15 AL, 250 V).

4. Screw the fuse holder cap back in place and reconnect power.

Signal Connections

The Maverick Storm 3 Profile can receive a DMX, Art-Net™, sACN, or a wireless Lumenradio CRMX™

signal. The product has 2 Seetronic Etherkon-compatible through ports and 5-pin DMX in and out ports. If

using other compatible products with this product, it is possible to control each individually with a single

controller.

Control Personalities

The Maverick Storm 3 Profile uses a 5-pin DMX data connection, Art-Net™, sACN, or wireless CRMX™

for its 2 control personalities, ranging from DMX Mode 34 Ch or DMX Mode 50 Ch.

DMX Linking

The Maverick Storm 3 Profile can link to a DMX controller using a 5-pin DMX connection or a CRMX™

connection. For more information about DMX, read the DMX primer at:

https://www.chauvetprofessional.com/wp-content/uploads/2016/06/DMX_Primer.pdf

Remote Device Management

Remote Device Management, or RDM, is a standard for allowing DMX-enabled devices to communicate

bi-directionally along existing DMX cabling. Check the DMX controller’s User Manual or with the

manufacturer as not all DMX controllers have this capability. The Maverick Storm 3 Profile supports RDM

protocol that allows feedback to make changes to menu map options.

Art-Net™ Connection

Art-Net™ is an Ethernet protocol that uses TCP/IP which transfers a large amount of DMX512 data using

an ethernet connection over a large network. An Art-Net™ protocol document is available from

www.chauvetprofessional.com

Art-Net™ designed by and copyright Artistic Licence Holdings Ltd.

sACN Connection

Also known as ANSI E1.31, streaming ACN is an Ethernet protocol that uses the layering and formatting of

Architecture for Control Networks to transport DMX512 data over IP or any other ACN compatible network.

• Always connect the product to a protected circuit (a circuit breaker or fuse). Ensure the

product has an appropriate electrical ground to avoid the risk of electrocution or fire.

• To eliminate unnecessary wear and improve its lifespan, during periods of non-use

completely disconnect the product from power via breaker or by unplugging it.

Never connect the product to a rheostat (variable resistor) or dimmer circuit, even if the

rheostat or dimmer channel serves only as a 0 to 100% switch.

Connection Wire (U.S.) Wire (Europe) Screw Color

AC Live Black Brown Yellow or Brass

AC Neutral White Blue Silver

AC Ground Green/Yellow Green/Yellow Green
