5E
BASIC USE OF MIXES ON EXIT™ SETTING ADJUSTMENT
Set sprayer knob adjustment (pull to turn) to desired amount of concentrate sprayed per gallon. Fill
Chemical tank with exact amount of chemical to cover the square footage per Chemical manufacturer’s
instructions. Example: 1 ounce for 10 square feet. Evenly spray and cover the desired 10 square foot area
until concentrate tank is empty. Note: Setting 1 will mix less chemical with water - setting 7 will allow more
concentrate to be mixed with water when spraying. The water is the vehicle in which the chemical is being
delivered. As long as you cover the desired predetermined area with the appropriate amount of chemical
the amount of water is inconsequential. Setting the mix ratio helps you control how quickly the chemical is
delivered per gallon.
FINE TUNING YOUR MIXES ON EXIT™ SPRAYER
(Use this process for calibrating your mix ratio settings)
1) Fill the concentrate tank and backpack tank - both with water.
2) Weigh the Concentrate tank and record the weight.
3) Set the dial to the desired position (example: set to 1 for 1 ounces per gallon).
4) Weigh your empty bucket (record the weight for future reference if your scale doesn’t have a
tare function).
5) Keeping the bucket on the scale, spray 1 gallon of water (adding an additional 8.34 lbs to the
empty weight of your bucket).
6) As you spray, keep your pump strokes consistent for most accurate measurement.
7) Remove the concentrate tank from the backpack sprayer and weigh the tank with it’s remaining
chemical in the tank.
8) Subtract the current weight of concentrate tank from the weight recorded in step 2.
9) Calculate the mix ratio using the following equation:
10) If results are slightly off from the expected mix ratio,
set knob –/+ to accommodate variance and retest to confirm accuracy.
Once confirmed note setting that provides exactly 1 ounce per gallon.
11) Repeat as needed for a range of settings
Mix Ratio =
127.9356
TOTAL WT OF WATER
CHANGE IN WT OF
CONCENTRATE TANK
(
)
– 1
NOTE:
• Be sure to pull and turn the mix ratio dial when choosing your setting.
• Always follow chemical manufacturer’s instructions.
• When not spraying, set mix ratio dial to zero.
• Approximate mix ratios based on chemical concentrates
with approximate viscosity to water while pumping at a
rate of 60 beats per minute.
• Pumping faster than 60 BPM will result in higher mix ratios
and pumping slower will result in lower mix ratios.
Setting Ounces Per Gallon
1
0.5 oz. per gallon
2
2.0 oz. per gallon
3
3.5 oz. per gallon
4
5.0 oz. per gallon
5
6.0 oz. per gallon
6
7.0 oz. per gallon
7
8.0 oz. per gallon
8
8.5 oz. per gallon
9
9.0 oz. per gallon
10
9.5 oz. per gallon
SETTINGS GUIDE
Chapin Backpack Sprayer Operator’s Manual - English
