8RS660-101022
Input
The INPUT control is variable, and allows adjustment of in-
coming signals applied at the XLR input connector on the
rear of the compressor. The INPUT control is labeled —
from left to right — 0 to10.
The RS660 is a variable-mu type compression circuit. Clock-
wise adjustment of the INPUT control simultaneously raises
incoming signal level, while lowering the compressor’s thresh-
old and increasing the amount of compression applied to the
source material.
Counterclockwise rotation of the INPUT control simultane-
ously reduces incoming input level, while raising the thresh-
old and lowering the amount of compression applied to the
source material.
Tip: To obtain lower input levels and thus less compression
and higher resultant output, run the RS660 Compressor as a
send in a parallel compression scheme.
4
0
6
7
8
9
5
I0
-4
-3
-2
-I
0
-6
-7
-8
-9
-5
-I0
OUTPUT
INPUT
THD
COMP
LIMIT
LINK
4
3
2
I
0
6
7
8
9
5
I0
-4
0
-6
-7
-8
-9
-5
-I0
OUTPUT
INPUT
dB
COMPRESSION
3
0
0
2
0
1
5
1
0
5
Output
The OUTPUT control is a variable attenuator, use this control
to lower the overall output level of the RS660. Rotation in
a counterclockwise motion from right to left, beginning at 0
and continuing to -10 will attenuate the output signal of the
RS660 to the desired level.
Note: For an additional fee, switched I/O controls can be
pre-ordered at time of purchase from an authorized Chan-
dler Limited dealer.
