The system supports several standard Layouts, including a standard Group, Position, Colour,
Beam programming layout.
On Stadium consoles there are 12 Layouts on the left side of the right hand display. Further
layouts can be accessed by pressing CTRL.
On Compact consoles Window layouts are recalled by pressing CTRL and selecting one of the
top soft buttons. There are also three physical Layout buttons, which together with SHIFT can
select Layouts 1 to Layout 6.
Shift Functions
The MagicQ lighting console uses SHIFT and CTRL buttons to enable access to advanced
features. There is a SHIFT button and a CTRL button adjacent to the top corners of the touch
screen in addition to the keys on the keyboard.
The SHIFT button is used with the cursor keys to enable selection of multiple items in
Windows.
The ALT button is used to access functions which are supported by physical buttons on some
consoles but not on others. For example, ALT is used to access PAGE UP and PAGE DOWN on
Compact and Stadium consoles.
The Programmer
All recording of show data is carried out using the Programmer. The Programmer takes
priority over all playbacks, and channels. It can also be used during live running to override
the outputs – for example, for changing the colour or gobo of intelligent heads.
The Programmer can be considered to be a table of channel level and active flags for each of
the channels patched onto the console. Initially all channels are set to their default values.
When a channel is changed, the channel level for that entry in the table is set to the new level
and the channel is flagged as active.
The console outputs any channels that are marked as active in the Programmer at highest
priority – i.e. they over-ride all other playbacks.
To clear the Programmer press CLEAR. All channels will be deactivated and all HTP channels
will be set to zero. Depending on the "unused Channels return to defaults" setting, LTP
channels will either stay at their current values or return to their defaults. It is possible to
force all LTP channels to zero by using CTRL CLEAR.
The programmer can be set into a Blind mode using the BLIND button so that the contents of
the programmer do not affect the output of the console. This allows programming
adjustments to be made during a live show and special effects to be "busked" in.
36 ChamSys Manuals 2025-02-12
