ChamSys adds new personalities for heads as the information becomes available. If a
personality is not available then it can be requested from ChamSys. Users also have the ability
to create the personality themselves in the inbuilt Head Editor.
HTP / LTP channels
The console supports two types of channels, highest takes precedence (HTP) and latest takes
precedence (LTP). Generally HTP channels are used for channels controlling dimmers and for
the dimmer channel of intelligent heads. LTP channels are used for the attributes of
intelligent heads such as pan, tilt, colour, gobo etc…
For HTP channels the value that is output is the highest value of that channel on all of the
active playbacks and the programmer. The console can be configured so that if a HTP channel
is in the programmer it always overrides any active playbacks.
For LTP channels the value output is the value from the last active playback unless that
channel is active in the programmer in which case the value output is the value stored in the
programmer.
The last active playback is the last playback to be raised above zero, which is still above zero.
Playbacks that are bumped in using ADD or SWAP buttons automatically become the last
active playback until the button is released.
The type of channel used by the console is determined by the personality used to patch the
dimmer or intelligent head.
Intensity channels should always be patched as HTP. In addition Red, Green, Blue channels in
fixtures that do not have an Intensity channel are patched as HTP. All other channels are
patched as LTP.
Playbacks can be set so that all channels controlled by the Playback act in a LTP way, thus
allowing Intensity channels to be overridden by a single Playback.
The Patch HTP also affects the operation of channel releasing, Grand Master and DBO as in
the table below:
Feature Patch HTP Patch HTP (Cue Stack
All Chans Controlled
LTP)
Patch LTP
Channel mixing HTP LTP LTP
Channels release to 0 Yes Yes No
Fader controls level Yes Yes No
GM/DBO controls
level
Yes Yes No
2025-02-12 ChamSys Manuals 33
