MagicQ Wings for use with PC/Mac
The MagicQ Mini Connect, MagicQ Compact Connect and MagicQ Stadium Connect products
connect directly to a PC or Mac. The PC or Mac runs the MagicQ software and processes the
Cues whilst the wing acts as a physical surface with faders, buttons and encoders and outputs
DMX.
Previous models included the MagicQ Mini Wing, MagicQ PC Wing and MagicQ Maxi Wing.
Plugging Up
All MagicQ consoles and SnakeSys interfaces have auto ranging power supplies and can
accept 110V to 240V AC on the powercon socket.
• Connect the power lead to the power socket labelled LINE INPUT.
• Put the console lamp(s) into the console lamp socket(s)
MagicQ consoles support USB keyboards and mice. It is not necessary to connect the mouse.
The mouse is only required if the touch screen becomes damaged.
Note that the power cable lead should be connected before other connectors and should
remain connected at all time that other connections such as DMX, network, serial, USB or
video are connected to the console. This ensures that the console is correctly grounded.
DMX Connections
MagicQ consoles have 4 direct DMX outputs on the rear of the panel so you can connect your
DMX cables direct to the console.
Alternatively you can connect to an Ethernet network using the Art-Net, Pathport or ACN
Streaming DMX protocols and use external Ethernet to DMX converters to output the DMX.
The network ports on MagicQ consoles all have auto MDI/MDIX detection so a normal or
inverted network cable can be used to connect to other network devices. Most modern
laptops and computers also have auto MDI/MDIX detection.
ChamSys offer a range of Ethernet to DMX convertors branded SnakeSys. These can be used to
8 ChamSys Manuals 2025-02-12
