OPERATIONOPERATION
DH3000 / MD2000 PLUS / DHT cycle is approximately 1 minute and consists of a wash,
dwell, rinse and sanitary dwell time. If the Varicycle button is pressed during a wash cycle, the
display will indicate machine is in Varicycle mode and the wash cycle timer is now set to 16
minutes. If the Varicycle button is pressed for a second time during a wash cycle, Varicycle
is removed from the display and machine immediately progresses to rinse and sanitary dwell
cycles (unless the wash cycle is less than 40 seconds: the machine is allowed to nish the
remainder of the 40 second wash cycle before progressing to rinse and sanitary dwell).
DH3000 / MD2000 PLUS / DHT
Cycle Approx. 1 minute
DH3000 / MD2000 PLUS / DHT
Cycle Times
Wash (displayed WASH) 35 seconds
Dwell (not displayed) 1 second
Rinse (displayed RINSE) 7 seconds
Sanitary Dwell (displayed DWELL) 17 seconds
(cont. on next page)
CYCLE TIME
(section end)
1. Turn the main power on at the main circuit breaker.
2. Make sure the spray arms and the scrap screens are in
place.
3. Turn the water supply on.
4. Close the dishwasher front door.
5. Check the chemical levels in the containers.
6. Push the green power button on. The power button will
illuminate and the machine will fill with water (see Fig. 46).
7. FILLING is displayed as machine fills automatically.
8. READY is displayed when the machine is filled (see Fig. 47).
OPERATION SEQUENCE
START-UP STEPS
WINSTON-SALEM,NC
CHAMPION INDUSTRIES, INC.
10
0
30
20
PSI
60
50
40
Fig. 46 - Power button on starts machine lling
WINSTON-SALEM,NC
CHAMPION INDUSTRIES, INC.
10
0
30
20
PSI
60
50
40
Fig. 47 - Ready screen after preheating
NOTE
It is recommended the tank temperature
is 150 °F / 66 °C before washing wares.
Allow 10 minutes for machine to preheat.
36
