11008 - 10,000 LB. WINCH
SPECIFICATIONS
13
SPECIFICATIONS
Performance Specifications
Rated Pull ...................... 10000 lb. (4536 kg)
Gear Reduction Ratio ......................... 216:1
Motor..... Permanent magnet 3.6 HP/2.7 kW (DC 12V)
Drum Size ...... 2.5 in. × 8.8 in. (63 mm × 224.5 mm)
Rope Dimensions .. 3/8 in. × 85 ft. (9.2 mm × 25.9 m)
Gross Weight ...................... 92.5 lb. (42 kg)
Net Weight ......................... 85 lb. (38.6 kg)
Mounting Bolt Pattern
.............................
10 in. × 4.5 in. (25.4 cm × 11.4 cm)
Overall Dimensions ................................
21.9 in. (L) × 5.6 in. (W) × 10.5 in. (H)
55.5 cm × 14.2 cm × 26.7 cm
Line Speed and Motor Current (First Layer)
Line Pull
LB
0
2000 4000 6000 8000 10000
KG 0 907 1814 2722 3629 4536
Line Speed (12V DC)
FPM 15.7 9.8 7.2 5.9 4.9 3.9
MPM 4.8 3.0 2.2 1.8 1.5 1.2
Max Current A 115 175 220 280 320 400
Run Time* Minutes 1 1 1 1 1 1
Cooling Time** Minutes 5 5 5 5 5 5
* If the motor becomes uncomfortably hot to the touch, stop winching immediately and let it cool down for 5 minutes. Do not pull for more than
one minute at or near the rated load.
* *Electric winches are designed and made for intermittent use and should not be used in constant duty applications.
Line Pull and Cable Capacity Per Layer
Line of Cable
1
2 3 4
Rated Line Pull
LB 10000 8000 6600 5600
KG 4536 3629 2994 2540
Cable Capacity
FT 18 39.4 64 85
M 5.5 12 19.5 25.9
– Use double line and snatch block for pulling loads over 50%.
