IRONHERO 1200 MANNEQUIN DRY

38

ENGLISH

adjusted the rod, re-tighten the clip. Fig. 4

3. Insert the upper rod (a) into the hole at the bottom of the collar section of the hanger.

Fig. 5

4. Insert the non-drip protector into the lower rod (c). Fig. 6

5. Insert the above assembly into the hole on the surface of the motor unit as shown in

Figure 7.

6. Fix the balloon for top garments to the mounting ange and make sure that no air leaks

from the bottom. The seam of the balloon should coincide with the centre of the edge of

the motor unit as much as possible. Fig. 8-9

7. Dress the balloon with the garment (as shown in Figure 10) and ensure the following:

- The collar of the garment is well positioned.

- That the buttons (if the garments has any) are centred on the front of the balloon.

- The arms of the balloon t with the sleeves of the garment and do not wrinkle or twist.

- The garment is fully buttoned.

Warning

Make sure the balloon is well xed to the mounting ange and that there are no air leaks.

Assembly for bottom garments

1. Remove the hanger and collar section assembly. Fig. 11

2. Loosen the height-adjustment clip and pull the upper rods (a) to adjust the height. Once

the desired height has been set, re-tighten the clip. Fig. 12

3. Insert the lower rods (b) into the Y-shaped bracket. Fig. 13

4. Insert the support rod (c) into the bottom of the Y-shaped bracket. Then insert the

non-drip protector into the support rod (c). Fig. 14-15

5. Insert the above assembly into the hole on the surface of the motor unit as shown in

Figure 16.

6. Fix the balloon for bottom garments to the mounting ange and make sure that no air

leaks from the bottom. The seam of the balloon should coincide with the centre of the

edge of the motor unit as much as possible. Fig. 17-18

7. Dress the balloon with the bottom garment and make sure it ts well and does not twist

or wrinkle. All buttons and zips (if there are any) must be fastened. Fig. 19

Warning

Make sure the balloon for bottom garments is well xed to the mounting ange and that there

are no air leaks.

Using the counterweight clamps

1. The counterweight clamps help to better stretch the garment vertically for improved

ironing.
