Assembling the xing frame and propeller to the rear of the helicopter

Figure 7

1. Fixing frame

2. Fixing frame gasket

3. Fixing nut

4. Fixing frame installation hole

5. LED light

6. Fixed decorative head

7. Propeller

8. Limiting tab

9. Limiting sleeve

10. Fixed toothed tube

11. Limiting slots

- Place the xing frame in the corresponding hole and secure it with the gasket and nut.

Follow the same process for both xing frames.

- Insert the sleeve into the tube at the rear of the helicopter. Then, insert the tabs into the

slots. Finally, x it all together with the decorative head.

Hanging the fan

Figure 8

1. Mounting bracket

2. Fixing nut

3. Fixing screws

Figure 9

1. Connecting bolt

2. Fixing seat

3. Downrod

4. Fixing slot

5. Connecting bolt

Figure 10

1. Fixing seat

2. Fixing piece

3. Fixing screws

1. Remove the xing piece from the mounting bracket and keep it aside.

2. Insert the connecting bolt into the downrod hole and then, insert the downrod into the

xing seat on the mounting bracket.
