BOLERO DRESSCODE 8970/9970/10970 DIRECT DRIVE/STEEL

86

ENGLISH

Fig. 7 key:

1. Standard tap

2. Long tap

3. Square tap

The water hose connector is located at the rear of the washing machine as shown in gure 8.

Connect the hose to the pipe and tap as follows:

1. Check the rubber seals on both ends of the hose. Insert a rubber seal into the threads of

each hose to prevent leaks. Fig. 9

Fig. 9 key

1. Rubber seal

2. Hose (to supply water to the washing machine)

2. Connect the water supply hoses to the water taps rmly by hand and then tighten a further

2/3 turn with pliers. Connect the blue hose to the water tap. Fig. 10

Warning: Do not overtighten. This could damage the coupling.

3. After connecting the inlet hose to the washing machine, open the water taps to ush out

any foreign substances (dirt, sand or sawdust) from the water pipes. Let the water run into

a bucket and check the water temperature. Fig. 11

4. Connect the hoses to the water inlet rmly by hand and then tighten a further 2/3 turn

with pliers. Fig. 12

Warning: Do not overtighten the hoses. Excessive tightening may damage the valves and

cause leaks.

5. Check for leaks by opening the taps. If water leaks occur, repeat steps 1 to 4.

- Remove the stopper if the washing machine will be used for a long period of time.

- Remove the plug and disable the door lock function to prevent children becoming trapped

inside.

- Packaging materials (e.g. lm, foam) can pose a safety hazard to children and cause

suocation. Warning: Keep all packaging materials out of reach of children.

Drain hose installation

- Secure the drain hose with a lifting rope.

- To avoid damage caused by oor leakage, position the drain hose correctly.

- To avoid siphoning, the drain hose height should be between 0.85 m-1.25 m, and the end

should not be submerged in water. Fig. 13

- If the drainpipe is too long, do not force it into the washing machine, as this may cause

abnormal noise.
