BOLERO DRESSCODE 8970/9970/10970 DIRECT DRIVE/STEEL

84

ENGLISH

3. INSTALLATION

Installation instructions

- Make sure the washing machine is installed in a location where the temperature is above

0 °C or place it indoors.

- Install the washing machine correctly according to this instruction manual and local

regulations.

- Keep the washing machine base well-ventilated when it is placed on a carpeted oor.

- Any damage caused by cockroaches or other pests is not covered by the warranty.

Transport bolts

Transport bolts are tted to prevent internal damage during transport.

Removing the transport bolts

1. 4 bolts are installed to prevent internal damage during transport. Before using the washing

machine, remove these bolts. Fig. 2. Failure to do so will result in severe vibrations, noise

and malfunction.

2. Use the supplied spanner to loosen all 4 bolts. Fig. 3

3. Slightly rotate the bolt rubber and then remove the bolts. Keep the bolts and spanner for

future use. Fig. 4.

The bolts must be retted when transporting the washing machine.

4. Use the supplied caps to seal the bolt holes. Fig. 5

Note: Do not disassemble the xing device from the drainpipe.

Placement requirements

Fig. 6

1. Drain hose

2. Sink

3. About 2 cm

Level adjustment

- The tilt angle must not exceed 1 degree.

Power socket

- The distance between any side of the washing machine and the power socket must be 1.5

metres.

- Do not use too many electrical appliances in one socket.
