Bolero CoolMarket Chest 142 Black /White E

Bolero CoolMarket Chest 199 Black/White E

Bolero CoolMarket Chest 254/299/400/500 White E

Bolero CoolMarket Chest 142 Black /White E

Bolero CoolMarket Chest 199 Black/White E

Bolero CoolMarket Chest 254/299/400/500 White E

6968

ESPAÑOL

27. Remove the washer and nut xing the pin screw to the right side hole of the bottom hinge.

Next, remove the pin screw and the two pin shafts from the bottom hinge. Fig. 6.

28. Install the pin screw in the left side hole and insert the pin shafts into the adjacent holes.

After that, secure the pin screw using the washer and nut. Fig. 7

NOTE: if your model uses bottom hinges, refer to the following steps:

- Remove the pin shaft from the right side hole of the bottom hinge. Fig. 8

- Insert the pin shaft into the left side hole of the bottom hinge. Fig. 9

29. Install the bottom hinge on the left side of the refrigerator body and install the adjustable

foot on the right side of the refrigerator body. Fig. 10

30. Remove the screw securing the door stops on the bottom right side of the freezer-

compartment door, then remove the door stops and install them on the bottom left side.

Fig. 11

NOTE: some models use this type of door stops, please reverse them using the same method.

Fig. 12

31. Install the freezer-compartment door.

32. Remove the cover from the door bushing hole in the top left side of the freezer door, then

move the door bushing from the top right side of the door to the top left side of the door.

Install the hole cover into the bushing hole at the top right side of the door. Fig. 13

33. Remove the plugs from the screw holes of the centre hinges on the left side of the

refrigerator body and install the plugs in the screw holes on the right side of the refrigerator

body. Fig. 14

34. Install the centre hinge on the left side with the two screws previously removed. Fig. 15

35. Remove the screw securing the door stops from the bottom of the refrigerator door, then

remove the door stops and install them on the bottom left side. Fig. 16

NOTE: some models use this type of door stops, please reverse them using the same method.

Fig. 17

36. Install the refrigerator-compartment door.

37. Remove the cover from the door bushing hole at the top left of the refrigerator compartment

door and move the door bushing from the top right side of the door to the top left side of

the door. Fig. 18

38. Remove the hinge screw hole cover from the top left side of the refrigerator body and

install it on the top right side of it. Fig. 19

39. Remove the cable terminal from the top left side of the refrigerator compartment door,

connect the cable terminal to the refrigerator body on the left side (only suitable for

models with external display). Attach the top hinge to the top left side of the refrigerator

Fig. 14 key:

1. Plugs

Fig. 15 key:

1. Centre hinge spacer

2. Centre hinge

3. Door bushing

4. Screws

Fig. 16 key:

1. Refrigerator-compartment door

2. Door stops

Fig. 18 key:

1. Door bushing

2. Bushing hole cover

3. Refrigerator compartment door

Fig. 19 key:

1. Hinge screw hole cover

Fig. 20 key:

1. Hinge cover

2. Screws

3. Top hinge

If the appliance is turned upside down or on its side during this process, it should be left in an

upright

position for 6 hours before plugging it in to prevent damage to the internal components.

21. Make sure the refrigerator is unplugged.

22. Remove the screw that secures the right hinge (if present), pry up and remove the top

hinge cover, remove the screws that attach the top hinge to the door, remove the cable

terminal that connects the door and the refrigerator body (this step is only suitable for

models with external display) and then remove the hinge. Fig. 3

23. Remove the refrigerator-compartment door from the refrigerator body.

24. Remove the screws securing the centre hinge and remove it. Fig. 4

25. Remove the freezer-compartment door.

26. Remove the screws securing the bottom hinge from the bottom right side and remove the

hinge. Then, remove the adjustable foot from the left side of the refrigerator. Fig. 5
