ENGLISH ENGLISH

- The appliance should be kept away from damp or wet environments. Water or dirt should

be removed from any surface of the appliance as soon as possible with a soft cloth. This

will help prevent rust and help your appliance run at maximum eciency.

- Place the refrigerator in a well-ventilated place, reserve some space around and behind

the refrigerator, and do not cover or block the air grille of the compressor rear cover plate

at the back of the refrigerator. Keep the refrigerator away from heat sources or direct

sunlight.

Adjustable feet (Fig. 7)

- In the refrigerator packing box, feet come tightly packed. After removing the refrigerator

from the box for installation, be sure to adjust the two front feet to the desired height;

adjust the two feet with a spanner or directly by hand.

- The feet and rear rollers must touch the oor to prevent the refrigerator from moving,

vibrating, or rattling.

- When moving the refrigerator, adjust the feet counterclockwise so that they do not touch

the oor, then gently tilt the refrigerator to start moving it.

Door shelf

- Disassembly: hold both sides of the door shelf with both hands. Hold the sides of the door

shelf with both hands. Push it in from the side opposite the slot and push it in as shown

in Figure 8. Push until the edge of the door shelf separates from the groove in the slide.

- Assembly: hold the sides of the door shelf with both hands. Install the clip on the slot rst.

Then, push the other side slightly inwards–the clip will click into place on the slot and the

door shelf will be installed. Make sure the appliance is installed correctly before using it.

(Fig. 8)

Fig. 8 key:

1. Door-shelf slide

2. Door lining

3. Door shelf

Instructions for locking the water dispenser (Fig. 9)

- Push the child safety lock lever with your thumb as shown in Figure 9 (arrow 1)–the lever

(2, Fig. 9) will lock and it will, in turn, lock the water dispenser.

- Push it in the opposite direction to unlock the water dispenser.

Instructions for installing the water tank (Fig. 10)

- Grasp both sides of the tank with your hands and pull the tank assembly slightly upwards

out of the door.

- Turn the water valve assembly counterclockwise to remove it from the water tank for

cleaning.

- Move the tab on the water-tank cover slightly upwards to detach the water-tank cover

Refrigerator compartment

The refrigerator compartment is to be used primarily for storing food that will be consumed

within a short time.

Freezer compartment

- The freezer compartment is used for freezing food, storing deep-frozen food, and making

ice cubes. It can preserve food for a long time.

- If the interior is stained with oil or fatty foods, it should be cleaned immediately to avoid

prolonged contact with the coating and subsequent corrosion and cracking.

- The two-star drawers ( ) are suitable for storing pre-frozen food, storing, or making ice

cream and making ice cubes.

- Drawers with one ( ), two ( ), or three ( ) stars are not suitable for freezing fresh

food.

- If you don’t intend to use the device or if it will stay empty for a long period of time, unplug

it, allow it to defrost, clean it, dry it, and leave the door open to avoid the formation of

mould inside it.

Automatic defrosting

The appliance is equipped with a programme that controls the frequency and duration of

freezer defrosting. This allows for the freezer to defrost automatically, sparing you the trouble.

LED display and temperature control

The display shows the temperature of the refrigerator compartment and the freezer

compartment respectively. To change the setting in either of the two compartments, simply

press the up or down arrow depending on the change you wish to make.

Removable and easy-to-clean door seal

The door seals are easy to remove and clean, allowing for ecient, long-lasting operation.

Carrying

- Do not carry the refrigerator horizontally or lying down.

- Do not carry the refrigerator by the door or handle; carry the refrigerator by lifting from

the bottom.

- Never carry the appliance alone–at least two people are required for safe lifting or carrying

of the appliance.

Installation location

- The refrigerator must be placed on a solid, at surface.

- If cushioning is necessary, use stable, solid, and non-ammable cushioning blocks.

- DO NOT USE FOAM PACKAGING AS CUSHIONING BLOCKS!
