17

Connect the motor cable to the power supply (19), using the rst port avail-

able: if only one LIFTO 25 is being connected to the power supply (19),

choose the port “1” (22).

Connect the wired input device (25) to the power supply (19), via the RJ45

port labeled “A1” (24) or “A2” (23).

An extension cord, 2 m long, for the motor cable is provided in the kit, if

needed. The input device cable can be extended as well, using the provided

RJ45 coupler and a standard Ethernet cable (not included). Extensions ex

-

ceeding 50 mt (164 Ft) are not advisable.

Finally, connect the power supply (19) to a AC plug via the AC port (18),

using the provided cable.

! The power supply can handle up to four LIFTO 25 at

the same me. Please be advised that all the motorized

elevaon units (7) connected to the same power supply

(19), will move simultaneously and not independently

one from the each others.

In case you need to connect more than one LIFTO 25 to the same power

supply unit (19), please proceed following the increase numbering of the

motorized elevaon unit output ports.

To set the tripod height release the spreader knob (4) and then loose the

three leg clamp lever (2). Li the tripod pulling up the tripod base (6) ll

the desired height, then lock in place the three extendable legs (13) with

the three leg clamp levers (2). Adjust the opening angle of the legs (13) and

ghten the spreader knob (4). Finally, if needed, adjust the extension of the

spreader acng on the adjusng boon (5).

Set the horizontal poson of the tripod base (6) trimming the length of each

leg conveniently, loosing and then ghtening the leg clamp lever (2). Check

the bubble level embedded (12).
