Expanding your CSD25M!
The CSD25M allows for the following pads and upgrade packs to be added to your drum set:!
Carlsbro TOM4 8” single zone mesh tom pad with accessories: CSDPK-T8MP
Carslbro CRASH2 10” single zone cymbal pad w/choke with accessories: CSDPK-C10B
Carlsbro 10” dual zone mesh snare pad with accessories: CSDPK-T10MP!
Carlsbro upright mesh bass pad and tower stand: CSDPK-MBP
Carslbro bass drum kick pedal with beater (used with CSDPK-MBP): CSDPK-PDL1
Carslbro hardware open/close hi-hat with accessories: CSDPK-OCHH2
All above expansion packs include all the required hardware and accessories.!
Contact your Local Carlsbro retailer or distributor for further information and availability.!
MIDI settings
This device is compatible with various MIDI software, hardware and GM standard.!
Connection for MIDI control and recording:!
1. Connect the sound module USB output to a computer with a USB A to USB B cable (not
included).!
2. Software should automatically register the sound module as a USB MIDI input. !
3. Select or create a MIDI track.!
4. Select a software drum kit or instrument. !
5. Set the track input as a USB MIDI device.!
6. Play the pads to control your chosen software instrument.!
Connection for tutorial software:!
1. Connect the sound module USB output to a computer with a USB A to USB B cable (not
included).!
2. Software should automatically register the sound module as a USB MIDI input. !
3. If needed, set the software input device as USB MIDI.!
4. Play the pads to control your tutorial software.!
If your software is unable to recognise certain pads, you can adjust the output MIDI notes for
each pad to correspond with your software:!
1. Press the VOICE button until you reach the MIDI note setting, n??!
2. Strike the pad you need to adjust.!
3. Use the adjustment wheel to select the required MIDI note for your software.!
4. Press the SAVE button to save these settings as a USER DRUM KIT U??!
CSD25M default MIDI notes
TRIGGER
MIDI!
NOTE
TRIGGER
MIDI!
NOTE
TRIGGER
MIDI!
NOTE
KICK
36
TOM3
43
CRASH
49
SNARE RIM
37
HI-HAT PEDAL
44
RIDE
51
SANRE
38
TOM2
45
CRASH2
57
TOM4
41
HI-HAT OPEN
46
HI-HAT CLOSED
42
TOM1
48
19
