39
ENG
iJW +0300103EN rel. 1.1 - 31.03.2025
Index
Humidifi er output (par. DOu)
Select the humidifi cation output (see “Humidity management”).
Par. Description Def Min Max UOM User User terminal
DOu Assign humidifi cation digital output - see DOA ... 0 6 - S NO
Reverse dead band output (par. DOv)
Select reverse output for dead band control (see “Control”).
Par. Description Def Min Max UOM User User terminal
DOv Assign reverse digital output with dead band control - see DOA ... 0 6 - S NO
Auxiliary parallel compressor (par. DOw)
Select the auxiliary parallel compressor output (see “Control”). Setting this output enables an auxiliary compressor that works in
parallel with the main compressor. A delay time can be set using parameter c11 to avoid simultaneous starts.
Par. Description Def Min Max UOM User User terminal
DOw Assign auxiliary parallel compressor digital output - see DOA ... 0 6 - S NO
c11 Second compressor start delay 4 0 250 s S NO
Gasket heater (par. DOx)
Select the digital output for the door gasket heater (see “Gasket heater”).
Par. Description Def Min Max UOM User User terminal
DOx Assign gasket heater digital output - see DOA ... 0 6 - S NO
Auxiliary compressor with rotation (par. DOy)
Select the output for the auxiliary compressor with rotation (see “Control”). Setting this output enables an auxiliary compressor
that is activated as a second control step, with rotation, i.e. alternating with the compressor that starts fi rst so as to balance the
operating hours of the two compressors. In the event of simultaneous request for both steps, the second compressor is activated
after a delay time set by parameter c11, to avoid simultaneous starts.
Par. Description Def Min Max UOM User User terminal
DOy Assign auxiliary compressor with rotation digital output - see DOA ... 0 6 - S NO
c11 Second compressor start delay 4 0 250 s S NO
External dehumidifi er (par. DOz)
Select the digital output for activation of an external dehumidifi er (see “Humidity management”).
Par. Description Def Min Max UOM User User terminal
DOz Assign external dehumidifi er digital output - see DOA ... 0 6 - S NO
7.4.1 Test output mode
The iJW controller provides the possibility to test the operation of the outputs, either from the Applica Desktop confi guration
software or via the Applica app, by accessing Service area > Test mode.
Par. Description Def Min Max UOM User User terminal
Mr1 Test mode, activate relay1: 0 = disabled; 1 = automatic; 2 = activated 1 0 2 - S NO
Mr2 Test mode, activate relay 2 - see Mr1 1 0 2 - S NO
Mr3 Test mode, activate relay 3 - see Mr1 1 0 2 - S NO
Mr4 Test mode, activate relay 4 - see Mr1 1 0 2 - S NO
Mr5 Test mode, activate relay 5 - see Mr1 1 0 2 - S NO
Mr6 Test mode, activate relay 6 - see Mr1 1 0 2 - S NO
Mt Manual mode duration (0 = manual mode always active) 10 0 90 min S NO
Parameters Mr* are used to activate the relays manually:
• Mr* = 0 the corresponding relay is deactivated;
• Mr* = 1 the corresponding relay is activated/deactivated automatically by the controller based on the associated function;
• Mr* = 2 the corresponding relay is activated.
The message ‘Man’ is shown on the display when at least one output is set in manual mode.
After a time set using parameter Mt, automatic operation resumes.
Caution: If Mt = 0 operation remains in manual mode until automatic operation resumes.
