Hecu +0300023EN rel. 1.2 - 14.12.2021
Par Description Cat. Def Min Max UOM
A3 Disable door switch
0=enabled
1=disabled
doL 1 0 1 -
tLi Light off delay doL 120 0 240 min
A4 Light management
0 = door switch + light button
1 = light button
doL 0 0 1 -
Tab. 7.l
H0: Serial address
Parameter H0 defi nes the Ultracella serial address.
Par. Description Def Min Max UOM
H0 Serial address 199 0 199 -
Tab. 7.m
The addresses must obey the following logic:
Device Address
Ultracella 1 11
Ultracella 2 12
Ultracella 3 13
Ultracella 4 14
Ultracella 5 15
While the other parameters that select the protocol are:
• H7 = 0 Carel protocol
• H7 = 1 Modbus protocol
H7 must be = 1, while the other parameters retain the default settings,
and are:
Par. Description Def Min Max UOM
H10 BMS communication speed bit/s
0 1200 5 38400
1 2400 6 57600
2 4800 7 76800
3 9600 8 115200
4 19200 9 375000
40 9 -
H11 BMS stop bits
1 1 stop bit
2 2 stop bit
21 2 -
H12 BMS parity
0no
1 odd
2even
00 2 -
Notice: to activate the changes, power the unit off and on again.
Cold room temperature control
Cold room temperature is managed by modulating the electronic
expansion valve.
Probe con guration
UltraCella controllers have a maximum of fi ve analogue inputs, three
of which can be confi gured as temperature probes (NTC probes, high
temperature NTC, PT1000), and the fourth as a temperature probe
or 0-10 V input, the fi fth can be confi gured as a 4
- 20 mA or 0- 5 Vrat input.
Analogue inputs Type
B1
B2
B3
NTC10 kΩ at 25°C, range -50T90°C,
NTC extended range, NTC50 kΩ at 25°C, range 0T150°C;
PT1000, 1000 Ω at 0°C, range -50T90°C
B4 NTC10 kΩ at 25°C, range -50T90°C,
NTC extended range, NTC50 kΩ at 25°C, range 0T150°C
0-10 V
B5 4-20 mA
0-5 Vrat
0.5-4.5 Vrat
Tab. 7.n
The parameters and corresponding settings are shown below.
Par. Description Def Min Max UOM
/P Type B1…B3
0 = NTC Standard Range -50T90°C
1 = NTC Enhanced Range 0T150°C
2 = PT1000
002-
/P4 Type B4
0 = NTC Standard Range -50T90°C
1 = NTC Enhanced Range 0T150°C
2 = 0-10 V
002-
/P5 Type B5
0 = 4-20 mA
1 = 0-5 Vrat
2= 0.5-4.5 Vrat
002-
Assign functions of probes B1, B2, B3, B4, B5
Inside the cold room, the controller can use the following probes:
• outlet;
• intake:
• defrost, placed on the evaporator, preferably where ice forms the most.
Probe B1 is confi gured as a room temperature ambient probe and its
function cannot be changed.
Par. Description Def Min Max UOM
/A2 B2 confi guration
0 Absent
1 Defrost probe 1 (Sd1)
2 Intake probe (Sr)
3 Generic temperature probe 2
103-
/A3 B3 confi guration
0 Absent
1 Defrost probe 2 (Sd2)
2 Cond. probe (Sc)
3 Defrost probe 1 (Sd1)
4 Room probe (SA)
5 Generic temperature probe 3
005-
/A4 B4 confi guration
0 Absent
1 Room temperature probe (SA)
2 Humidity probe
3 Generic temperature probe 4
4 Generic humidity probe 4
004-
/A5 B5 confi guration
0 Absent
1 Humidity probe
2 Generic temperature probe 5
3 Generic humidity probe 5
4 Generic pressure probe 5
5 Condensing pressure probe (Scp)
005-
For probe B4, if confi gured as a 0-10 V input (/ P4 = 2) and for probe B5,
the logic to be used for control corresponding to the physical full scale
values can be confi gured.
Par. Description Def Min Max UOM
/4L
Minimum value of probe 4 (0-10 V input
only)
0 -50.0 /4H -
/4H Maximum value of probe 4 (0-10 V input
only)
100.0 /4L 200.0 -
/5L Minimum value probe 5 0 -50.0 /5H -
/5H Maximum value of probe 5 100.0 /5L 999 -
Example: if a pressure sensor with a 4-20 mA output in the range -1 to 9.3
bars is connected to input B5, set
- /5L = -1.0
- /5H = 9.3
In this case, when the probe reads 12 mA, the value associated with the
reading will be 4.1 (half scale).
