Instruction manual DD782BK Please keep this instruction manual for future reference16
CHILD LOCK
Press the child lock button for about 3 seconds to lock the controls. When
you lock the appliance, 'Lo' will appear on the screen. When child lock is
enabled, all keys are disabled except the On/Off button.
NOTE: When you turn off the hob with the key lock enabled, you will
not be able to activate the hob without disabling the child lock.
TIMER
Select the burner button for which you want to set the timer and press the timer
button ( ). Then set the 1st digit of the timer to the desired level in the leveling
panel and press the timer button to confirm, then set the 2nd digit of the timer to
the desired level in the lev-eling panel and press the timer button. When the timer
mode is activated, the display of the selected area flashes and a "dot" ( .)
appears at the bottom right of the display.
If the timer is also selected in more than one zone, the timer indi-cator will rotate
clockwise and will be displayed every 5 seconds.
Left rear cooker indicator
Select the left rear hotplate for power or timer setting. A blinking LED indicates
that the hotplate is selected and shows the level "0", the power level can be
adjusted with the slider.
Left front hob indicator
Select the left front hotplate for power or timing setting. A blinking LED indicates
that the hotplate is selected and shows level "0", the power level can be adjusted
with the slider.
CHILD LOCK
Press the child lock button for about 3 seconds to lock the controls. When
you lock the appliance, 'Lo' will appear on the screen. When child lock is
enabled, all keys are disabled except the On/Off button.
NOTE: When you turn off the hob with the key lock enabled, you will
not be able to activate the hob without disabling the child lock.
TIMER
Select the burner button for which you want to set the timer and press the timer
button ( ). Then set the 1st digit of the timer to the desired level in the leveling
panel and press the timer button to confirm, then set the 2nd digit of the timer to
the desired level in the lev-eling panel and press the timer button. When the timer
mode is activated, the display of the selected area flashes and a "dot" ( .)
appears at the bottom right of the display.
If the timer is also selected in more than one zone, the timer indi-cator will rotate
clockwise and will be displayed every 5 seconds.
Left rear cooker indicator
Select the left rear hotplate for power or timer setting. A blinking LED indicates
that the hotplate is selected and shows the level "0", the power level can be
adjusted with the slider.
Left front hob indicator
Select the left front hotplate for power or timing setting. A blinking LED indicates
that the hotplate is selected and shows level "0", the power level can be adjusted
with the slider.
RIGHT REAR HOB INDICATOR
Select the right rear cooking zone for power or timer setting. A blinking LED
indicates that the hotplate is selected and shows level “0”, the power level can
be adjusted with the power level control.
RIGHT FRONT HOB INDICATOR
Select the right front cooking zone for power or timer setting. A blinking LED
indicates that the hot-plate is selected and shows level “0”, the power level can
be adjusted with the slider.
PRESET TEMPERATURE FUNCTION
After selecting any of the cooking zones, press the Preset temperature button to
enter the preset temperature mode. 3 levels can be selected, with each touch of
the button [1-2-3-off].
Used for thawing food and defrosting frozen food. 50˚C
Used for heating or keeping food warm. 70˚C
It is used to boil, slow cook or keep food 90˚C
close to boiling temperature.
PAUSE
Press the pause button to enter pause mode, all cooking zones and ventilation
will stop. To deactivate the pause mode, press the pause button twice briey.
If you do not cancel the pause mode 10 minutes after activating it, the appliance
will automatically turn itself off.
EXTRACTION ON/OFF
Press the button to start extraction, then use the speed levels slider to set
the desired level.
To switch the extractor off, press the hood on/off button twice quickly.
*Press and hold for 3 seconds to activate/deactivate the automatic mode.
Filter warning LED
When the grease filter expires (60 hours), the grease filter symbol flashes once
per second for a total of 5 seconds. After 5 seconds, the grease filter symbol
illuminates in the background until deactivated.
To reset the filter symbol and the metal oil filter countdown timer after cleaning/
replacing your metal oil filter, press the timer button ( ) for 3 seconds.
30.04.2025
FLOW-IN PRO GOOD PLUS USER MANUAL EN
38
PAUSE
Press the pause button to enter pause mode, all cooking zones and
ventilation will stop. To deactivate the pause mode, press the pause button
twice briefly.
If you do not cancel the pause mode 10 minutes after activating it, the device
will automatically turn itself off.
Right rear hob indicator
Select the right rear hotplate for power or timer setting. A blinking LED
indicates that the hotplate is selected and shows level "0", the power level
can be adjusted with the slider.
Right front hob indicator
Select the right front hot-plate for power or timing setting. A blinking LED
indicates that the hot-plate is selected and shows level "0", the power level can
be adjusted with the slider.
KEEP WARM FUNCTION
After selecting any of the burners, press the keep warm button to enter keep
warm mode, 3 levels can be selected, press the keep warm button to increase
the level and turn off (1-2-3-off).
30.04.2025
FLOW-IN PRO GOOD PLUS USER MANUAL EN
37
Used for thawing food and defrosting
frozen food.
50˚C
Used for heating or keeping food warm.
70˚C
It is used to boil, slow cook or keep food
close to boiling temperature.
90˚C
Right rear hob indicator
Select the right rear hotplate for power or timer setting. A blinking LED
indicates that the hotplate is selected and shows level "0", the power level
can be adjusted with the slider.
Right front hob indicator
Select the right front hot-plate for power or timing setting. A blinking LED
indicates that the hot-plate is selected and shows level "0", the power level can
be adjusted with the slider.
KEEP WARM FUNCTION
After selecting any of the burners, press the keep warm button to enter keep
warm mode, 3 levels can be selected, press the keep warm button to increase
the level and turn off (1-2-3-off).
30.04.2025
FLOW-IN PRO GOOD PLUS USER MANUAL EN
37
Used for thawing food and defrosting
frozen food.
50˚C
Used for heating or keeping food warm.
70˚C
It is used to boil, slow cook or keep food
close to boiling temperature.
90˚C
Right rear hob indicator
Select the right rear hotplate for power or timer setting. A blinking LED
indicates that the hotplate is selected and shows level "0", the power level
can be adjusted with the slider.
Right front hob indicator
Select the right front hot-plate for power or timing setting. A blinking LED
indicates that the hot-plate is selected and shows level "0", the power level can
be adjusted with the slider.
KEEP WARM FUNCTION
After selecting any of the burners, press the keep warm button to enter keep
warm mode, 3 levels can be selected, press the keep warm button to increase
the level and turn off (1-2-3-off).
30.04.2025
FLOW-IN PRO GOOD PLUS USER MANUAL EN
37
Used for thawing food and defrosting
frozen food.
50˚C
Used for heating or keeping food warm.
70˚C
It is used to boil, slow cook or keep food
close to boiling temperature.
90˚C
Right rear hob indicator
Select the right rear hotplate for power or timer setting. A blinking LED
indicates that the hotplate is selected and shows level "0", the power level
can be adjusted with the slider.
Right front hob indicator
Select the right front hot-plate for power or timing setting. A blinking LED
indicates that the hot-plate is selected and shows level "0", the power level can
be adjusted with the slider.
KEEP WARM FUNCTION
After selecting any of the burners, press the keep warm button to enter keep
warm mode, 3 levels can be selected, press the keep warm button to increase
the level and turn off (1-2-3-off).
30.04.2025
FLOW-IN PRO GOOD PLUS USER MANUAL EN
37
Used for thawing food and defrosting
frozen food.
50˚C
Used for heating or keeping food warm.
70˚C
It is used to boil, slow cook or keep food
close to boiling temperature.
90˚C
