Instruction manual C8242C Instruction manual C8242C
24 25
Please keep this instruction manual for future reference
Please keep this instruction manual for future reference
INSTALLATION
Cut out the work surface according to the sizes shown in the drawing. For the purpose of
installation and use, a minimum of 50mm space must be left around the hole. If installing with
xing clips, a work surface of at least 30mm should be used. Due to the limits of the xing clips, If
the work surface is less than 30mm, add a small strip of heat resistant material to the underside
of the surface. This will increase the surface depth for the clips to attach to. Please select heat-
resistant work surface material to avoid deformation caused by the heat radiation from the hob.
See below:
L [MM] W [MM] H [MM] D [MM] A [MM] B [MM] X [MM]
770 520 55 51 754 499 50 [min]
WARNING:
Always ensure the hob is well ventilated and the air inlet and outlet are not blocked. Ensure the
ceramic hob is in good working order. See below:
A [MM] B [MM] C [MM] D E
760 50 [min] 20 [min] Air intake Air exit [5mm]
Under any circumstances, the brackets cannot touch with the inner surfaces of the worktop after installation (see picture). This will
ensure the hob is properly secured to the underside of the work surface.
NOTE:
For safety, the distance between the hob and the cupboard above should be at least 760mm.
STIR-FRYING
1. Choose a compatible at-based wok or a large frying pan.
2. Have all the ingredients and equipment ready. Stir-frying should be quick. If cooking large
quantities, cook the food in several smaller batches.
3. Preheat the pan briey and add two tablespoons of oil.
4. Cook any meat rst, put it aside and keep warm.
5. Stir-fry the vegetables. When they are hot but still crisp, turn the cooking zone to a lower setting,
return the meat to the pan and add your sauce.
6. Stir the ingredients gently to make sure they are heated through.
7. Serve immediately.
HEAT SETTINGS
The settings below are guidelines only. The exact setting will depend on several factors, including
your cookware and the amount you are cooking. Experiment with the hob to nd the settings that
best suit you.
HEAT SETTING SUITABILITY
1-2
Delicate warming for small amounts of food
Melting chocolate, butter, and foods that burn quickly
Gentle simmering
Slow warming
3-4
Reheating
Rapid simmering
Cooking rice
5-6 Pancakes
7-8
Sautéing
Pasta
9
Stir-frying
Searing
Bringing soup to the boil
Boiling water
