ORIFICE CHANGE - RANGETOP SECTIONS
(CONTINUED)
POWER WOK BURNER
These models are equipped with a large dedicated cast iron wok ring permanently attached to
the rangetop.
‘W’ versions (such as MCR362W) feature a larger version of the Sealed Burner seen on page 5.
‘CW’ versions (such as MCR362CW) use the same Open Burner as seen on page 4.
Follow the same orice changing process as those burners.
There is no need to remove the wok ring.
1. Remove the cast iron cross insert (if installed) and set aside.
2. Follow the same procedure as seen on page 3-4 (Open) or 5-6 (Sealed). Do not use any pipe
dope or sealant on the threads. Install the new orice slowly to avoid cross-threading and
damaging the threads. Consult the table below for identication of orice sizes.
POWER WOK SEALED - Large 30000 25000
ALTITUDE
RANGE/RANGETOP
MODEL FAMILY
BURNER LOCATION BURNER TYPE
NG LP
ORIFICE ORIFICE
(BTU/hr.)
ORIFICE INFO
Sea Level - 1999 . [600 m]
2000 - 6000 . [600 - 1800 m]
MCR, GSCR, GRT
‘CW’ VERSIONS
RANGETOP ORIFICES
ALTITUDE
RANGE/RANGETOP
MODEL FAMILY
BURNER LOCATION BURNER TYPE
NG LP
ORIFICE
SIZE
LP
ORIFICE
SIZE
43 * 54
BURNER OUTPUT
(BTU/hr.)
ORIFICE INFO
Use #43 orifice on 30” wide appliances at sea level - 1999 ft. [600 m].
Use #45 orifice on 30” wide appliances at high altitude 2000 - 6000 ft. [600 - 1800m].
NG
Sea Level - 1999 . [600 m]
2000 - 6000 . [600 - 1800 m]
40 * 53
MCOR, CGSR, CGRT
MCR, GSCR, GRT
‘W’ VERSIONS
*
*
43 1.45mm
POWER WOK OPEN 25000 25000
45 54
SIZE
BURNER OUTPUT
NG
LP
SIZE
30000 BTU/Hr Sealed Wok Burner
© 2025 Capital Cooking
10
