The hob may be nstalled n any worktop whch s heat resstant to a
temperature of 100°C, and has a thckness of 25-45 mm. The
dmensons of the nsert to be cut out of the worktop are n shown n
Fgure 2.
When there s an accessble space between the bult-n hob and the
cavty below, a dvdng wall made of nsulatng materal should be
nserted (wood or a smlar materal) (Fgure 3).
The dstance between the hob and any other unt or applance above t
(e.g. An extractor hood) must be no less than 70 cm . (Fgure 4)
Metal objects n the drawer may reach hgh temperatures due to
ar recrculaton. It s therefore recommended to use an
ntermedate wood panel.
Important - The dagram n figure 1 shows how the sealant should
be appled.
The Hob unt s fitted by attachng the Fxng Clamps suppled, usng
the holes at the base of the unt.
When a 60 cm hob s fitted over a bult n oven, the latter
fan cooled.
1.1 BUILDING IN
2. ELECTRICAL CONNECTION (FOR U.K. ONLY)
Warnng - ths applance must be earthed
Ths applance s desgned for domestc use only. Connecton to the man
supply must be made by a competant electrcan, ensurng that all current
regulatons concernng such nstallatons are observed.
The applance must only be connected to a sutably rated spur pont, a
3 pn 13 amp plug/socket s not sutable. A double pole swtch must be
provded and the crcut must have approprate fuse protecton.
Further detals of the power requrement of the ndvdual product wll
be found n the users’ nstructon and on the applance ratng plate. In
the case of bult-n product you are advsed, should you wsh to use a
longer cable than the one suppled, that a sutably rated heat resstant
type must be used.
The wrng must be connected to the mans supply as follows:
CONNECT TO SPUR TERMINAL
Green & Yellow Wre Earth Connecton
Blue Wre Neutral Connecton
Brown Wre Lve Connecton
Note: We do not advocate the use of earth leakage devces wth
electrc cookng applances nstalled to spur ponts because of the
«nusance trppng» whch may occur. You are agan remnded that the
applance must be correctly earthed, the manufacturer declnes any
responsblty for any event occurrng as a result of ncorrect electrcal
nstallaton.
2.1. ELECTRICAL CONNECTION
Check the data on the ratng plate, located on the outsde of the unt, to
ensure that the supply and nput voltage are sutable.
Before connecton, check the earthng system.
By Law, ths applance must be earthed. If ths regulaton s not compled
wth, the Manufacturer wll not be responsble for any damage caused to
persons or property. If a plug s not already attached, fit a plug
approprate to the load ndcated on the ratng plate. The earth wre s
coloured yellow/green. The plug should always be accessble.
Where the Hob s connected drect to the electrcty supply, a crcut
breaker must be fitted.
If the power supply cord s damaged ths s to be replaced by a qualfied
engneer so as to prevent any potental rsk.
The earth wre ( green and yellow coloured ) must be at least 10 mm
longer than the lve and neutral wres.
The secton of the cable used must be of the correct sze n relaton to
the absorbed power of the hob.
Please check ratng plate for the power detals and ensure that the
power supply cord s of the type 3x0.75 mm² H05-V2V2-F for 60cm
hobs.
LIVE
EARTH
NEUTRAL
L
N
Power Cable
Brown Wre
Green/Yellow Wre
Blue Wre
Mans Supply
If an applance s not fitted wth a supply cord and a plug, or wth other
means for dsconnecton from the supply mans havng a contact
separaton n all poles that provde full dsconnecton under overvoltage
category III condtons, the nstructons shall state that means for
dsconnecton must be ncorporated n the fixed wrng n accordance wth
the wrng rules.
1. INSTRUCTIONS FOR THE INSTALLER
INSTALLING A DOMESTIC APPLIANCE CAN BE A COMPLICATED OPERATION WHICH IF NOT CARRIED OUT CORRECTLY, CAN SERIOUSLY
AFFECT CONSUMER SAFETY. IT IS FOR THIS REASON THAT THE TASK SHOULD BE UNDERTAKEN BY A PROFESSIONALLY QUALIFIED
PERSON WHO WILL CARRY IT OUT IN ACCORDANCE WITH THE TECHNICAL REGULATIONS IN FORCE. IN THE EVENT THAT THIS ADVICE IS
IGNORED AND THE INSTALLATION IS CARRIED OUT BY AN UNQUALIFIED PERSON, THE MANUFACTURER DECLINES ALL RESPONSIBILITY
FOR ANY TECHNICAL FAILURE OF THE PRODUCT WHETHER OR NOT IT RESULTS IN DAMAGE TO GOODS OR INJURY TO INDIVIDUALS.
These instructions are for qualified personnel, installation of
equipment must be in line with the relevant national standard. (For
U.K. only: by law the gas installation\commissioning must be
carried out by a "Gas Safe" installer)
All work must be carried out with the electricity supply disconnected.
The rating plate on the hob shows the type of gas with which it is
designed to be used. Connection to the mains gas supply or gas
cylinder should be carried out after having checked that it is regulated
for the type of gas with which it will be supplied. If it is not correctly
regulated see the instructions in the following paragraphs to change
gas setting.
For liquid gas (cylinder gas) use pressure regulators which comply
with the relevant national standards.
Use only pipes,washers and sealing washers which comply with the
relevant national standards.
For some models a conic link is furnished to outfit for the installation in
the countries where this type of link is obligatory; in picture 8 it is
pointed out how to recognize the different types of links (CY =
cylindrical, CO = conic). In every case the cylindrical part of the link
has to be connected to the hob.
When connecting the hob to the gas supply via use offlexible hoses
please ensure that the maximum distance covered by the hose does
not exceed 2 metres.
The flexible tube shall be fitted in such a way that it cannot come into
contact with a moveable part of the housing unit (e.g. a drawer) and does
not pass through any space where it may become crushed/ kinked or
damaged in any way.
To prevent any potental damage to the hob please carry out the
nstallaton followng ths sequence (pcture 6):
1)As llustrated, assemble parts n sequence:
A: 1/2 Male Adaptor Cylndrcal
B: 1/2 Seal
C: 1/2 Female Gas Adaptor Concal-Cylndrcal or
Cylndrcal-Cylndrcal
2)Tghten the jonts wth the spanner, rememberng to twst the
ppes nto poston.
3)Attach fittng C to mans gas supply usng rgd copper ppe or
flexble steel ppe.
2.2. GAS CONNECTION
1.2. SUITABLE LOCATION
Ths applance must be nstalled n accordance wth the regulatons n
force and only used n a well ventlated space. Read the nstructons
before nstallng or usng ths applance.
WARNING: Pror to nstall, ensure that local dstrbuton condtons
(nature of the gas and gas pressure) and the adjustment of the
applance are compatble.
WARNING: The adjustment condtons for ths applance are stated on
the label (or data plate)
WARNING: Ths applance s not connected to a combuston products
evacuaton devce. It shall be nstalled and connected n accordance
wth current nstallaton regulatons. Partcular attenton shall be gven
to the relevant requrements regardng ventlaton. For ths reason you
should ensure good ventlaton ether by keepng all natural ar
passages open or by nstallng an extractor hood wth.
04 GB
If the hob is installed next to the cabinet on both sides, the distance
between the hob and the cabinet must be at least 15 cm. In this case, the
distance between the cutout and the back wall must be at least 60 mm for
60 cm hobs (4 gas - L1,L2 ).
must be
