Failure Display and Inspection
If an abnormality comes up, the induction hob will enter the protective state
automatically and display corresponding protective codes:
Problem
Possible causes
What to do
E4/E5
Temperature sensor failure
Please contact the supplier.
E7/E8
Temperature sensor of the
IGBT failure.
Please contact the supplier.
E2/E3
Abnormal supply voltage
Please inspect whether power supply
is normal.
Power on after the power
supply is normal.
E6/E9
Bad induction hob heat
radiation
Please restart after the induction hob
cools down.
The above are the judgment and inspection of common failures.
Please do not disassemble the unit by yourself to avoid any dangers and damages to the
induction hob.
Technical Specification
Induction Hob
CI642CBB
Cooking Zones
4 Zones
Supply Voltage
220-240V~ 50/60Hz
Installed Electric Power
7200W
Product Size D×W×H(mm)
590×520×58
Building-in Dimensions A×B (mm)
560×490
Weight and Dimensions are approximate. Because we continually strive to improve our products
we may change specifications and designs without prior notice.
Installation
Selection of installation equipment
• Cut out the work surface according to the sizes shown in the drawing.
• For the purpose of installation and use, a minimum of 50mm space shall be
preserved around the hole.
• Be sure the thickness of the work surface is at least 30mm. Please select heat-
resistant work surface material to avoid larger deformation caused by the heat
radiation from the hotplate. As shown below:
Warning: The work surface material must use the impregnated wood or other insulation
material.
L(mm) W(mm) H(mm) D(mm) A(mm) B(mm) X(mm)
CI642CBB/1 590 520 58 54 560 490 50mini
Under any circumstances, make sure the hob is well ventilated and the air inlet
and outlet are not blocked. Ensure the hob is in good work state. As shown below
Note: The safety distance between the hotplate and the cupboard above the hotplate
should be at least 760mm.
11
