28
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
Operating situation: As required
Maximum mounting
height:
Unlimited
Minimum distance to nor-
mal flammable materials:
0.5 m
Minimum distance to
illuminated surface:
0.5 m
Dimensions (W x H x L,
incl. mounting bracket):
209mm x
209mm x
203mm
287mm x
302mm x
239mm
342mm x
380mm x
259mm
415mm x
443mm x
288mm
Weight (incl. mounting
bracket + half glares-
hield):
4kg 9kg 13 kg 19 kg
Scope of delivery
(included):
Mounting ring for optional interchangeable lenses,
half-anti Glareshield
Accessories (optional):
Interchangeable lenses (20°, 40°, 55°, 60°x10°),
Full-Anti Glareshield, External Control Remote (UNICON)
EXPLANATION OF IP PROTECTION CLASS
1. An IP rating only reflects protection from solid objects and water. It does not describe general
weather resistance, such as protection from UV radiation and temperature, etc.
2. The first identification digit indicates protection from dust, solid objects and contact:
IP2X Protected against solid foreign bodies ≥ 12.5mm in diameter
IP3X Protected against solid foreign bodies ≥ 2.5mm in diameter
IP4X Protected against solid foreign bodies ≥ 1.0 mm in diameter
IP5X
Protected against dust in harmful quantities and completely protected against contact
protected
IP6X Are dust-tight and completely protected against contact
3. The second identification digit indicates protection from water:
IPX0 No protection
IPX1 Protection against dripping water
IPX2 Protection against dripping water when the device is tilted up to 15°
IPX3 Protection against falling spray water up to 60° from the vertical
IPX4 Protection against splashing water on all sides
IPX5 Protection against water jets (nozzle) from any angle
IPX6 Protection against strong water jets
IPX7 Protection against temporary immersion
4. In addition, some device-specific measures such as covers and sealing caps are necessary in
order to achieve the specified protection class (e.g. protective caps on unused connections).
The IP rating of the product can be found in the technical data and is printed on the
device.
