27
DMX
DEUTSCHFRANCAIS
ESPAÑOL
ENGLISH
ITALIANO POLSKI
TECHNICAL DATA
Product number: CLDS60 CLDS100 CLDS200 CLDS400
Product type: LED spotlight
Type: Installation spotlight
Colour spectrum: RGBW
Number of LEDs: 3 6 12 20
LED type: 4in1 Chip
LED output: 20W
Luminous flux: 1450lm 2800lm 7000lm 11000lm
LED PWM frequency: 650Hz, 1530Hz, 3600Hz, 12kHz, 18,9kHz, 25kHz (adjustable)
Half chaff angle: 6°
Tenths scattering angle: 11°
DMX input/output:
Permanently mounted 5-pin signal cable
(DMX In and Out), 2m, open ends
DMX functions:
Dimmer 8bit/16bit, RGBW, Strobe, CCT, Color Preset, Device Settings
(PWM, calibration, dimmer response , dimmer curve, record userco-
lor, factory reset)
Control: DMX 512, RDM
Standalone functions: Direct LED, Colour preset, CCT, Auto programme, Timer function
Operating controls: External Control Remote (UNICON)
Power consumption: 60 W 125 W 240W 400W
Inrush current:
57A / 0.21ms
(first half-wave)
70A / 0.3ms
(first half-wave)
40A / 1ms (first
half-wave)
57A / 0.75ms
(first half-wave)
Colour reproduction
index Ra:
>79 @8700K
Efficiency: 24lm/W 23lm/W 29lm/W 27,5lm/W
Power factor: >0,9 / 100-240V
Operating voltage: 100 - 277V AC / 50 - 60Hz
Power supply
connection:
Fixed power cable H07RN-F, 3 x 1.5 mm², 2 m, open ends
Surge protection: 4 KV
Ambient temperature
(in operation):
-20°C - 45°C
Housing colour: RAL 9017 - Traffic black
Housing material: Die-cast aluminium
Corrosion resistance: C5-M powder coating
Protection class: IP67
Cable glands: IP68
Impact resistance rating: IK 08
Housing cooling: Convection cooling
LED Lifetime: Minimum LED lifetime: 50,000 hours (to >70% luminous output)
