VI. Part List / CVC75
ITEM NO. DESCRIPTION QTY.
1 Roto molded Main Body 1
2 Roto molded Main Center Support 1
3 Roto molded lower shelfs packaged seperately with pawl, shoulder screw and tool (not shown) 2
4 Roto molded Square Support 2
5 Roto molded 6" Corner Support 4
6 Roto molded Main Shelf 1
7 Roto molded Center Cap 1
8 Roto plug- black (not shown) 8
9 PVC Drain Assy installed before foaming 2
10 See color code for wrap design 1
11 CSTR 6 x 2 Flt Trd SWB Prem 5
12 SS Banner Clamp bar 25.96" 2
13 6061-T6 Aluminum Anodized Black with 10-32 X 1.0" Threaded Holes at Each End 2
14 92311A433_18-8 SS Cup Point Set Screw 10-32 x 1.0 2 15 47227 Plug, Wing-Nut 2
16 91772A842 10-32 x 3.0" PHP SS 2
17 HDW #10 Washer SS 2
18 92105A430 Tapping Inserts for softwood 3/8-16 4
19 CVC75 Shelf Pawl Delrin Black Pkg with Lower Selfs 4
20 90298A578_18-8 SS Shoulder Screw Pk with Shelfs 4
21 91770A540 1_4 20 x 3_4 SS Phil Truss Hd 10
22 HDW SS Flat Washer 3/8" 24
23 92865A622_Medium-Strg Grade 5 Zinc-PLTD STL Cap Screw 20
24 CVC75 12" Front Window 2
25 Dowels 3/8" dia x 3/4" long 304SS 90145A622 8
26 92198A628_18-8 SS Hex Head Cap Screw 3/8-16 x 1.5" 2
27 12.55" X 12" Side Window 2
28 CVC75 .25" 304 SS rod x 15.5" threaded x 1.5" at each end 4
29 91950A029 1_4 Flt Wshr SS 8
30 1/4-20 Nyloc Hex Nut SS 8
31 3_8-16 x 3.0 HHCS 92198A636_18-8 Stainless Steel 2
32 CVC75 3/8 plastic plug 90221A225 Pk 25 $6.70 8
33 85985K290_Rigid Plastic Locking Plug 1.5 hole 6
34 92105A200 1/4-20 Alloy insert_after molding 4
35 92198A553_18-8 Stainless Steel Hex Head Cap Screw 1_4-20 x 2.75 4
36 Caster Swivel Lock for large pattern mounts 2
37 5/32" L-Key McM 6493A71 Not seen pkg with lower shelfs 1
38 9688K221_Rigid Plastic Snap-In Plug 1_4 12
39 1/4 x 1.0 Fender Washer SS 90377A157 4
